SKIP 130''-2-0
Command Pass: [AUTO] - [MARK EDITOR] - [SKIP]
This key is used so that the fiducial mark can be set to skip. When this key is pushed, the fiducial
mark is skipped and the image that was displayed on the screen is now processed as data .
If trying to skip a mark that has not been processed once, because important data is not recorded, an
alarm stating that the command is not recognized will display.
When the skip function is being used, "Skip" will display on the screen. After using the "SKIP" key,
the "CANCEL" key will display. When the operator wants to release from the skip mode, push the
"CANCEL" key. If Automatic production is then entered, that mark will be processed.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
BRIGHT 130''-4-0
Command Pass: [AUTO] - [MARK EDITOR] - [BRIGHT]
This key is used when camera offset and/or gain needs to be changed. To command page 522-2.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-4 CP643E System Reference
SPEED 130''-5-0
Command Pass: [AUTO] - [MARK EDITOR] - [SPEED]
This is used when slight changes or adjustments of the current position are required.
To command page 541.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
RETURN 130''-6-0
Command Pass: [AUTO] - [RETURN]
This is used when wanting to exit Mark Editor. The cross hairs displayed on the screen disappear
and Editor is exited after the previous changes have been saved.
Revision History
SEQ. NO 140-0-0
Command Pass: [AUTO] - [SEQ. NO]
Press to input the sequence number from which operation is to be started.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-5 CP643E System Reference
MODE 150-0-0
Command Pass: [AUTO] - [MODE]
Press to select production, simulate or idle mode.
Product: Regular operation is carried out.
Simulate: Only the X-, Y-, and D-axes move. Part pick-up is not carried out.
Idle: Continuous operation occurs without loader operation. Boards are not replaced
and image recognition is not performed.
Idle2: Continuous operation occurs with loader operation.
Boards are not replaced and image recognition is not performed.
Note: The production mode is automatically selected when the power supply is turned on.
Revision History
PRODUCT 151-0-0
Command Pass: [AUTO] - [MODE] - [PRODUCT]
Parts are picked up and placed on the boards. This is standard operation.
Revision History
SIMULATE 152-0-0
Command Pass: [AUTO] - [MODE] - [SIMULATE]
Parts are not picked up. The XY-table and the device tables operate as they do during production.
This mode is used for such things as verifying placing coordinates.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-6 CP643E System Reference
