Safety Guidelines Edition 1.0 6 CP643E System Reference Be sure to wear protective glasses. ● Be sure to wear protective glasses. [Example] CP-6 nozzles use springs which may be propelled during disassembly. Be sure to h…
Safety Guidelines
Edition 1.0 5 CP643E System Reference
Do not look into the conveyor inlet or outlet and do not
open the cover. (Reflow oven)
● Do not look into the conveyor inlet or outlet and do not open the
cover.
[Example]
The UV light on the reflow oven may damage eyesight or result in
burns.
Exchange the halogen lamp only after it has cooled
down.
● When turned on, halogen lamps will reach high temperatures,
resulting in skin burns when touched. To exchange a halogen
lamp, turn off the power and allow the lamp to cool off sufficiently.
Do not wear gloves made of cloth when operating the
machine.
● Rubber gloves will tear when caught by the machine and prevent
hands from being drawn into the machine. Gloves made of cotton
or similarly strong material may cause hands to be drawn into the
machine.
Long hair should be tied back.
● Long hair may get caught in running machines.
Hair should be kept short or tied back so that it does not get caught
in the machine.
Turn off the air supply when carrying out maintenance
on cylinders, valves, and filters.
● Removing cylinders, valves, or filters without turning the air supply
off, may cause parts or particles to be propelled into the eyes.
● Be sure to turn off the air supply when carrying out maintenance on
cylinders, valves, and filters.
WARNING
Safety Guidelines
Edition 1.0 6 CP643E System Reference
Be sure to wear protective glasses.
● Be sure to wear protective glasses.
[Example]
CP-6 nozzles use springs which may be propelled during
disassembly. Be sure to handle the nozzles carefully to prevent eye
injuries.
Check the machine monitor and the target axes
while manually operating the machine.
● When operating the machine, carefully follow the instructions that
are displayed at the machine display.
● Operating the machine without looking at the machine display may
lead to operating errors or result in damage to the machine or
products.
WARNING
CAUTION
Do not operate the machine after removing or disabling
sensors.
● Removing or disabling sensors will disarm the interlock, leading to
collisions and damage to the machine.
Check the machine display to determine whether
HELPS compatible machines are in the middle of
performing changeover.
● During operation in automatic mode on machines equipped with
automatic changeover equipment, it may be difficult to actually see
automatic changeover taking place from the front of the machine.
When a message appears at the machine display, follow the
instructions that are given.
Safety Guidelines
Edition 1.0 7 CP643E System Reference
3. Safety Rules for Individual Machine Types
CP-series Machines
WARNING
Do not reach into the machine over the rear fence
during operation.
● Body parts or clothing may be caught in the machine causing
personal injury.
Do not enter within the safety fence, even in cases of an
emergency stop.
● When an emergency stop occurs in step mode, power to the servo
amps is only cut after all axes have stopped moving. As a result,
there may be a short delay between the moment the emergency
arises and the power to the servo amps is cut.
● Do not enter the safety fence immediately following an emergency
stop, body parts or clothing may be caught in the machine causing
personal injury.
Do not operate the machine after removing the
transparent shutters from the D-axis.
● Body parts or clothing may be caught in the machine causing
personal injury.
Do not lean on the in- and out-conveyors during
operation.
● During operation do not lean on or across the in- and out-conveyors
to check the feeders.
Turn the power off when inspecting the cam box.
● When inspecting the upper part of the cam box, turn off the power
to the machine and exercise sufficient caution.
