Input 3 MX250 Address 0xef0240 LED No. No. Display Description A00 X040 SERVO BOX1 Servo box 1 functional A01 X041 SERVO BOX2 Servo box 2 functional A02 X042 TAPE END CHK Tape end detection A03 X043 L PICKUP CHK Station …

Input 2 MX250 Address 0xef0220

LED No. No. Display Description

A00 X020 MACHINE READY Machine is ready

A01 X021 AIR OK Air pressure check switch

A02 X022 THERMAL OK Thermal sensors functional

A03 X023 SERVO READY Servos functional

A04 X024 (Reserved)

A05 X025 Short circuit

A06 X026 Short circuit

A07 X027 Short circuit

A08 X028 FRONT DOOR OK Front door safety switch

A09 X029 REAR DOOR OK Rear door safety switch

A0A X02A LOADER PLC OK Board loader PLC functional

A0B X02B VACUUM OK Vacuum pressure check switch

A0C X02C CAM HANDLE CHK Cam handle switch

A0D X02D FEEDER CHK Feeder lifted

A0E X02E FENCE1 CHK Rear fence 1

A0F X02F FENCE2 CHK Rear fence 2

B00 X030 (Reserved)

B01 X031 BACKUP PIN CHK Backup pin detection

B02 X032 (Reserved)

B03 X033 PCB SET OK Reference pin inserted

B04 X034 FLWUP RAIL OUT Followup rail clutch engaged (outside)

B05 X035 FLWUP RAIL IN Followup rail clutch engaged (inside)

B06 X036 HARD READY Hardware ready

B07 X037 FEEDER CHK 18ST Station 18 interference (V1.34)

B08 X038 CONV PLUS OT Conveyor width (+) overtravel

B09 X039 CONV MINUS OT Conveyor width (-) overtravel

B0A X03A CONV PCB CHK Board on conveyor

B0B X03B REAR OPERATION Machine operated from rear panel

B0C X03C FEEDING FW POS Station 1 feeding lever advance limit

B0D X03D FEEDING BW POS Station 1 feeding lever retract limit

B0E X03E CAM ZERO POS Cam origin position

B0F X03F ST11 DN POS Station 11 cylinder lower limit (V1.41)

Part 6 Chapter 1 Standard I/O

Edition 1.0 6-1-2 CP643E System Reference

Input 3 MX250 Address 0xef0240

LED No. No. Display Description

A00 X040 SERVO BOX1 Servo box 1 functional

A01 X041 SERVO BOX2 Servo box 2 functional

A02 X042 TAPE END CHK Tape end detection

A03 X043 L PICKUP CHK Station 2 large parts pickup

A04 X044 PQ ROT. 270DEG Pretheta rotation cylinder advance

A05 X045 PQ ROT. 90DEG Pretheta rotation cylinder retract

A06 X046 SET CANCEL 1 Right device table set cancel

A07 X047 SET CANCEL 2 Left device table set cancel

A08 X048 MIDDLE DEVICE 50 / 50 feeder arrangement specified

A09 X049 HEAD A CHK Head A detection

A0A X04A NOZ CHK ST17 1 Station 17 nozzle type check 1

A0B X04B NOZ CHK ST17 2 Station 17 nozzle type check 2

A0C X04C NOZ CHK ST17 3 Station 17 nozzle type check 3

A0D X04D NOZ CHK ST19 1 Station 19 nozzle type check 1

A0E X04E NOZ CHK ST19 2 Station 19 nozzle type check 2

A0F X04F NOZ CHK ST19 3 Station 19 nozzle type check 3

B00 X050 PRQ ROT. 270DEG PRQ rotation cylinder advance

B01 X051 PRQ ROT. 90DEG PRQ rotation cylinder retract

B02 X052 NOZ ORG POS ST12 Station 12 nozzle clutch origin position

B03 X053 NOZ CLUT. ST 12 Station 12 nozzle clutch engaged

B04 X054 DUMP PARTS Reject parts box full

B05 X055 OIL ALARM Oil circulation alarm

B06 X056 NOZ ORG POS ST15 Station 15 nozzle clutch origin position

B07 X057 CYCLE MODE Cycle stop mode (V1.35)

B08 X058 SET COMPLETE1 Parts set complete 1

B09 X059 SET COMPLETE2 Parts set complete 2

B0A X05A SHUTTER1 UPCHK Shutter 1 raised

B0B X05B SHUTTER1 DNCHK Shutter 1 lowered

B0C X05C SHUTTER2 UPCHK Shutter 2 raised

B0D X05D SHUTTER2 DNCHK Shutter 2 lowered

B0E X05E TRANSFER IN In-conveyor board transfer

B0F X05F TRANSFER OUT Out-conveyor board transfer

Part 6 Chapter 1 Standard I/O

Edition 1.0 6-1-3 CP643E System Reference

Input 4 MX250 Address 0xef0260

LED No. No. Display Description

A00 X060 M-LFT CLMP F Main lifter board clamp (front side)

A01 X061 M-LFT CLMP R Main lifter board clamp (rear side)

A02 X062 M-LFT UNCLMP F Main lifter board unclamp (front side)

A03 X064 M-LFT UNCLMP R Main lifter board unclamp (rear side)

A04 X065 M-LFTR UP1 Main lifter upper limit 1

A05 X066 M-LFTR UP2 Main lifter upper limit 2

A06 X067 M-LFTR MO-TRVL Main lifter middle overtravel

A07 X067 M-LFTR DWN END Main lifter lower limit

A08 X068 XY IN L POS XY-table loading position (inside)

A09 X069 XY OUT L POS XY-table loading position (outside)

A0A X06A ST1 UP POS ST 1 cylinder upper limit

A0B X06B ST 11 UP POS ST 11 cylinder upper limit

A0C X06C (Reserved)

A0D X06D (Reserved)

A0E X06E (Reserved)

A0F X06F (Reserved)

Part 6 Chapter 1 Standard I/O

Edition 1.0 6-1-4 CP643E System Reference
