RCOM RESET 514-2-5 Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [RCOM RESET] Press to clear the contents of communication status memory. If the remote commands are not operating correctly, use this command to …
POSITION 1 514-2-4-1
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [ADJ. TEST] - [POSITION 1]
Press to conduct a conveyor width adjustment test. Enter a value from the numerical keypad.
Revision History
POSITION 2 514-2-4-2
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [ADJ. TEST] - [POSITION 2]
Press to conduct a conveyor width adjustment test. Enter a value from the numerical keypad.
The conveyor will move between position 1 and position 2.
Revision History
OFFSET 514-2-4-3
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [ADJ. TEST] - [ OFFSET]
Press to enable the operator to set a conveyor offset value into Proper data (27. Conveyor Stop
Offset). This value should be entered from the numerical input keypad.
The entry range is 0 mm to 1 mm.
Revision History
TARGET 514-2-4-4
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [ADJ. TEST] - [ TARGET]
Press to set the conveyor width target. The width will change from the setting in position 1 to
position 2 or vice versa when this key is pressed.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-43 CP643E System Reference
RCOM RESET 514-2-5
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [RCOM RESET]
Press to clear the contents of communication status memory. If the remote commands are not
operating correctly, use this command to reset the communication status.
Revision History
HOST 514-3-0
Command Pass : [SET] - [STATUS] - [LINE MODE] - [HOST]
Press this command to specify whether or not remote commands are to be used (this command only
displays when the SECS/GEM communication protocol is used).
Revision History
REMOTE / LOCAL 514-3-1
Command Pass : [SET] - [STATUS] - [LINE MODE] - [HOST] - [REMOTE / LOCAL]
Press this command to toggle the remote command mode.
REMOTE: Enables remote commands from the host.
LOCAL: Disables commands from the host.
Revision History
ETC 515-0-0
Command Pass : [SET] - [STATUS] - [ETC]
Press to access further commands.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-44 CP643E System Reference
TURNOVER 515-1-0
Command Pass : [SET] - [STATUS] - [ETC] - [TURNOVER]
Press to enable the turnover mode which is designed to improve the efficiency of the movement of
the device tables.
When in turnover mode, pressing this function key again will cancel the turnover mode.
Revision History
WARRANTY 515-2-0
Command Pass : [SET] - [STATUS] - [ETC] - [WARRANTY]
Press to access information about the status of the machine’s warranty period.
Note: The following displays when the 6000 hour warranty period for the equipment expires.
“Warranty period for this equipment is 6000 hours or 2 years”.
“Warranty period for this software is 2000 hours or 1 year”.
“Warranty period (6000 hrs) for this equipment has expired.”
Revision History
CANCEL MSG 515-2-1
Command Pass : [SET] - [STATUS] - [ETC] - [WARRANTY] - [CANCEL MSG]
Press to clear the warranty message.
This command is not available until the warranty period has been exceeded.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-45 CP643E System Reference
