NOZZLE DATA 523-1-5-1/2-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [NOZZLE DATA]
Display nozzle bend results.
Revision History
+PAGE 523-1-5-1/2-1-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [NOZZLE DATA] - [+PAGE]
Press to change the display from heads A~J to heads K~T.
Revision History
-PAGE 523-1-5-1/2-1-2
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [NOZZLE DATA] - [-PAGE]
Press to change the display from heads A~J to heads K~T.
Revision History
NOZZLE TYPE 523-1-5-1/2-1-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [NOZZLE DATA] - [NOZZLE TYPE]
This is used to change between nozzle No.1~3 and nozzle No. 4 ~ 6.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-77 CP643E System Reference
BACKLIGHT DATA 523-1-5-1/2-2
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [BACKLIGHT DATA]
Display nozzle back light measurement results.
Caution: The data displayed on the screen is the nozzle type data selected using the command. The
nozzle type display also changes accordingly.
When this screen is first opened (default), the No. 1 nozzle data is displayed.
The camera type selected using the higher order command will display in yellow.
In each data display, the value will display in white if it is within the tolerance range and in red if
it is not within the tolerance. In addition, for nozzles with a measurement error instead of a
value being displayed, “∗∗∗” will display in yellow.
Revision History
PAGE 523-1-5-1/2-2-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [BACKLIGHT DATA] - [PAGE]
The display toggles between the measurement results for nozzle heads A ~ J and K ~ T.
Revision History
CP643S3023
BACK LIGHT CONDITION
NOZZLE: 1
CAMERA: WIDE VIEW
Head
A
B
C
D
E
Gray
176
***
193
201
169
Dev
16
***
25
16
23
STANDARD VALUE
STANDARD DEV
Head
F
G
H
I
J
Gray
***
183
189
191
179
Dev
***
27
18
20
19
: 170 (± 20)
: 0 (+ 3)
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-78 CP643E System Reference
+NOZZLE 523-1-5-1/2-2-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [BACKLIGHT DATA] - [+NOZZLE]
Press to increase the nozzle number of the results being displayed by one. The nozzle following
nozzle 6 is nozzle 1.
Revision History
-NOZZLE 523-1-5-1/2-2-4
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE] / [NARROW] - [BACKLIGHT DATA] - [-NOZZLE]
Press to decrease the nozzle number of the results being displayed by one. The nozzle following
nozzle 1 is nozzle 6.
Revision History
NOZZLE SKIP 523-2-0
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [NOZZLE SKIP]
Enables nozzles to be skipped manually.
Revision History
NOZZLE TYPE 523-2-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [NOZZLE TYPE]
Press to choose from nozzle 1~6.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-79 CP643E System Reference
