(4) Press START

During automatic or step operation, when the command [AUTO], [STEP] or [POSITION]

have been chosen and the machine can safely carry out the operation requested, the

“Press START” message will appear. Press the START button after ensuring the machine

can safely carry out the operation.

(5) When the Machine Cannot Run

The following display will appear when the machine cannot start its next function.

When the problem displayed has been fixed the “Press START” message will appear.

Pressing the RETURN command key will restore the former situation without solving

the problem.

(6) Device Table Information in Device Change Mode

During device change mode operation when the feeder runs out of parts, the original

table will change and a display like the one below will be displayed. This display will

not disappear until parts have been set and the program has been changed.

CP643S1043

Producing ...

D000 supply

1ABC

2EFG

3LMN

4OPQ

5HIJK

6AT

000

Skip Nozzle Tape End

CP643S1042

Front Safety Door Open

1ABC

2EF

3HIJ

5OPQ

6BC

000

Skip Nozzle Tape End

CP643S1041

Press START

1ABC

2EFGHI

3DEF

4IJK

5LM

6AB

000

Skip Nozzle Tape End

Part 1 Chapter 1 Machine Overview

Edition 1.1 1-1-28 CP643E System Reference

1.4 Glossary

This chapter defines some of the terms used throughout this manual.

Advance Pick-Up

To increase throughput, parts are picked up for the next board, while that board is being

loaded.

Device Table

A rack onto which tape feeders are loaded, including the moving rack at the rear of CP-

series machines.

Global Skip Mark

Like a block skip mark, the machine inspects a specified location on the board for a mark

(this is the block skip mark position for block 0). If a mark is detected, the machine

knows that one of the blocks is to be skipped. In this case it will proceed with the

reading of all block skip mark areas. If no mark is detected, the machine knows all

blocks are to be produced. Global marks can be used to save the machine from having to

inspect for all the block skip mark areas on every board.

Inching

The action of manually moving one of the machine axes using the inching keys at the

machine control panel.

In/Out Carrier

The two mechanisms located over the in- and out-conveyor, which carry the board(s) to

and from the XY-table.

In/Out Lifter

The metal plates on the inside of the in- and out-conveyor which raises or lowers the

board(s) for clamping or releasing on the in- /out-carrier.

Proper Data

This is the data transmitted to the machine from the supervisor computer (MCS/F4G)

which provides the machine with all the data necessary for it to carry out operation

based on a production program. For example, Proper data tells the machine the position

of the cameras fitted on the machine.

Multiblock Board

A board which is made of smaller boards, which are divided up after the board is

complete. The smaller boards may be cut apart or simply snap apart as is the case with

multiblock boards using break away panels. Multiblock is also referred to as multipanel.

Nozzle Holder

A nozzle holder is attached to the end of each of the twenty placing heads on the turret.

Each nozzle holder can hold up to six different nozzles (see also Turret).

Part 1 Chapter 1 Machine Overview

Edition 1.1 1-1-29 CP643E System Reference

Production Program

A production program is the operating instructions to enable a machine to produce all or

a specified portion of a board.

Recovery

A function where by missed part placement sequences are reattempted by the machine

before the current board is unloaded. Missed sequences can occur when a part is

rejected by the vision system following inspection or a mispick occurs and so on. Based

on recovery, the machine automatically reallocates the missed sequence ensuring the

board is complete before it is unloaded. There are three modes of recovery, 'auto', 'error

stop' and 'error pass'.

Block Skip Mark

A block skip mark is made on a block of a multiblock board. The mark can either be

applied with a marker, or a sticker can be used. This is read by the mark camera to

indicate that parts should not be placed on that block.

XY-Table

The main conveyor onto which the board(s) is loaded during assembly.

Zero-Setting

Zero-setting is a function of the machine used to reposition the servo motors (which

control the machine axes). Zero-setting must be performed when the power to the

machine is turned on, as the positions of the servo motors are cleared from the machine

memory when the power is cut.
