▼ 523-1-1-3-1/2-1 Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [NZL TOL.] - [B_LITE STNDRD] - [WIDE]/[NARROW] - [ ▼ ] Select between standard value input and tolerance range input. Values for the standard value…
▼ 523-1-1-1-2
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [TOLERANCE] - [BEND LIMIT] - [▼]
Press to move the cursor down one line. Once the cursor has reached the bottom, if pressed again it
will move to the very top.
Revision History
B_LITE STNDRD 523-1-1-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [TOLERANCE] - [B_LITE STNDRD]
Set the nozzle back light reference value.
Revision History
WIDE 523-1-1-3-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [TOLERANCE] - [B_LITE STNDRD]
- [WIDE]
Set the reference and tolerance values for the wide view camera.
Revision History
NARROW 523-1-1-3-2
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [TOLERANCE] - [B_LITE STNDRD]
- [NARROW]
Set the reference and tolerance values for the narrow view camera.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-73 CP643E System Reference
▼ 523-1-1-3-1/2-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [NZL TOL.] - [B_LITE STNDRD]
- [WIDE]/[NARROW] - [▼]
Select between standard value input and tolerance range input.
Values for the standard value and the tolerance range can be input using the numerical keypad.
Revision History
WIDE 523-1-2
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [WIDE]
Press to display the wide camera measurement results.
Revision History
NARROW 523-1-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [NARROW]
Press to display the narrow view measurement results.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-74 CP643E System Reference
CALB SPC NZL 523-1-4
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [CALB SPC NZL]
Measure the center of rotation for a specified nozzle.
Input a target nozzle number. (Input range: 1 ~ 6)
If the measurement range is within the preset limits and the nozzle is not a skipped nozzle, the
START button is enabled.
If the nozzle is a skipped nozzle, a black nozzle or the measurement range is not within the preset
limits, the START button is not enabled. After input, if start conditions are satisfied, the START
button is enabled. Otherwise, the contents display in the second display area and the START button
is not enabled.
(Skip nozzles are the ones where the nozzle size in the nozzle arrangement table (NAT) is set to 0.)
The measurement results for the nozzle chosen are displayed. More than one nozzle cannot be
specified. If the results for more than one nozzle are needed, the command must be performed more
than once.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-75 CP643E System Reference
