IDLE 153-0-0
Command Pass: [AUTO] - [MODE] - [IDLE]
Continuous operation is performed without changing the board or performing vision processing.
The nozzles descend at stations 1 and 11. When using this mode, the feeders should be removed
from the tables.
Note: This mode should be used only for checking machine operation. It should not be used for production.
Revision History
IDLE 2 154-0-0
Command Path: [AUTO] - [MODE] - [IDLE2]
Continuous operation occurs with loader operation.
Boards are not replaced and image recognition is not performed. Nozzles are lowered at ST1 and
ST11. Operation should be performed with parts removed.
Note: The “Idle” mode is used only for checking machine operation. It is not used for production.
Revision History
CLEAR OFF / CANCEL 171-0-0
Command Pass: [AUTO] - [CLEAR OFF / CANCEL]
If CYCLE STOP is pressed the machine will stop after the current sequence is finished and the
display will return to command page 100.
If an error occurs the contents of the error are displayed in the second display area, production is
halted, and the RESET button is enabled. If RESET is pressed the display returns to command page
100.
CLEAR OFF: The message “Unloading...” displays in the first display area when this key is
pressed. After production of all boards in the machine is completed the RESET
button will be enabled.
CANCEL: The [CLEAR OFF] display changes to [CANCEL] when the clear off operation is
set. If this is selected the instruction for stopping after production of the boards in
the machine is complete will be canceled.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-7 CP643E System Reference
S STOP or D STOP / CANCEL 176-0-0
Command Pass: [AUTO] - [S STOP or D STOP / CANCEL]
If [CYCLE STOP] is pressed, the machine will stop after the current sequence is finished and the
display will return to command page 100.
If an error occurs the contents of the error are displayed in the second display area, production is
halted, and the RESET button is enabled. If RESET is pressed the display returns to command page
100.
S STOP: The message “Ending one board production” displays in the first display area when
this key is pressed. The display returns to command page 100 when placement on
the current board is completed.
D STOP: This displays when there are two boards on the main conveyor.
The message “Ending two board production” displays in the first display area when
this key is pressed. The display returns to command page 100 when placement on
the current board is completed.
CANCEL: The [S STOP / D STOP] display changes to [CANCEL] when [S STOP / D STOP] is
set. If this is selected the instruction to stop after production of the boards is
completed will be canceled.
Revision History
V1.10 and later
STEP 200-0-0
Command Pass: [STEP]
Press to carry out step operation of the machine.
Revision History
AUTO 210-0-0
Command Pass: [STEP] - [AUTO]
Press to carry out automatic operation of the machine.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-8 CP643E System Reference
Cam Org Pos 220-0-0
Command Pass: [STEP] - [Cam Org Pos]
Press to return cam axis to its origin position. While this key remains pressed the cam will move
toward its origin position. Movement stops when the cam returns to its origin. Movement also
stops if the key is released before the cam reaches its origin.
The message "Return Cam to Zero" displays in the second display area until the cam reaches its
origin. When the cam has returned the message "Press START" displays.
Revision History
MARK EDITOR 230-0-0
Command Pass: [STEP] - [MARK EDITOR]
Press to edit Fiducial Mark.
If there is not a Fiducial Mark Sequence in the production program, this cannot be used.
Refer to command page 130 for further details.
Revision History
SEQ. NO 240-0-0
Command Pass: [STEP] - [SEQ. NO]
The message “Sequence No.” will display in the second status area and the machine will then be
ready for sequence number input.
Press to input the sequence number from which operation is to start.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-9 CP643E System Reference
