SET 535-1-1/2-1
Command Pass: [SET] - [PROPER] - [Z] - [ZL] - [ZL_OUT] / [ZL_IN] - [SET]
This command sets the measured value in the relevant Proper data item.
Second display area
The message “Set Proper” will flash in green in this display area.
First status area
“ZL_OUT”, “ZL_IN”, “Z0”, Zmax”, “Zmin” or “M_load_Pos” will display, whichever is relevant.
Revision History
V1.10 and later
Z0 535-2-0
Command Pass: [SET] - [PROPER] - [Z] - [Z0]
This measures the “Z0” Proper data.
Revision History
V1.10 and later
Zmax 535-3-0
Command Pass: [SET] - [PROPER] - [Z] - [Zmax]
This sets the Z-axis positive direction Proper data item.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-101 CP643E System Reference
Zmin 535-4-0
Command Pass: [SET] - [PROPER] - [Z] - [Zmin]
This sets the Z-axis negative direction Proper data item.
Revision History
V1.10 and later
M_load_pos 535-5-0
Command Pass: [SET] - [PROPER] - [Z] - [M_load_pos]
This sets the “M_load_pos” Proper data.
Revision History
V1.10 and later
SERVO 540-0-0
Command Pass: [SET] - [SERVO]
Press to set servo parameters.
The servo counter is automatically displayed when the command [SERVO] is selected.
Caution : Holding down the inching shift key ([F]) while pressing RETURN will cause the servo counter display
to remain on the monitor.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-102 CP643E System Reference
SPEED 541-0-0
Command Pass: [SET] - [SERVO] - [SPEED]
Press to change the inching speed.
The inching speed can be entered in a range of 1 - 5 to change the slow inching speed of an axis.
A larger number will speed up the inching speed.
After the power is cut these changes are retained in memory.
Revision History
▲ 541-1-0
Command Pass: [SET] - [SERVO] - [SPEED] - [▲]
Press to move the cursor up one line to the servo axis to be changed.
Revision History
▼ 541-2-0
Command Pass: [SET] - [SERVO] - [SPEED] - [▼]
Press to move the cursor down one line to the servo axis to be changed.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-103 CP643E System Reference
