Part 4 Chapter 2 Details of Proper Data Edition 1.1 4-2-4 CP643E System Reference 12: Machine_Status B 0000 0000 0000 0000 # This sets special mode parameters (input as a 16 bit binary mask pattern) that are common to ev…
9: User_Define A 0000 0000 0000 0000 $#
Currently not in use.
Default: 0000 0000 0000 0000
11: Machine_Status A 0000 0000 0000 0000 *
This sets special mode parameters (input as a 16 bit binary mask pattern) that are common
to every machine.
Ensure the printer is connected when outputting to a printer. Production cannot be
guaranteed when outputting to a printer as this is for development only.
Default: 0000 0000 0000 0000
Special mode Bit map Decimal
The mark compensation value is printed out. 1000 0000 0000 0000 32768
The first device offset is printed out during automatic 0100 0000 0000 0000 16384
operation.
Global skip mark enabled. 0000 0000 1000 0000 128
Check mode for all devices. 0000 0000 0100 0000 64
Machine stops if all the blocks are skipped. The block 0000 0000 0010 0000 32
skip marks are reread when the machine is restarted.
The number of parts used by each nozzle is reported 0000 0000 0001 0000 16
(production data).
Remote commands enabled. 0000 0000 0000 1000 8
Board check by means of block skip marks 0000 0000 0000 0100 4
Set to enter the [MARK EDITOR] command if a mark 0000 0000 0000 0001 1
reading error occurs.
Part 4 Chapter 2 Details of Proper Data
Edition 1.1 4-2-3 CP643E System Reference
Part 4 Chapter 2 Details of Proper Data
Edition 1.1 4-2-4 CP643E System Reference
12: Machine_Status B 0000 0000 0000 0000 #
This sets special mode parameters (input as a 16 bit binary mask pattern) that are common
to every machine.
Ensure the printer is connected when outputting to a printer. Production cannot be
guaranteed when outputting to a printer as this is for development only.
Default: 0000 0000 0000 0000
Special mode Bit map Decimal
Set when the vision processing debug mode is 1000 0000 0000 0000 32768
specified for nozzle center measurement.
Print out the results of the X, Y-axis placement 0100 0000 0000 0000 16384
position calculations.
Print out the results of nozzle center measurement. 0010 0000 0000 0000 8192
This is a debug function for checking the vision 0001 0000 0000 0000 4096
processing compensation values.
The device shaft advance return mode is not used. 0000 0100 0000 0000 1024
Not in use. 0000 0000 1000 0000 128
The parts reloading position on the CP-6 is 0000 0000 0100 0000 64
changed from 45 to 55.
Change the data check standard. If this bit is set, 0000 0000 0010 0000 32
the PD pickup offset (22.D_ofst_x) for devices
1, 70, 71 and 140 is satisfactory if it is within
± 5.0 mm.
Parts interference prevention (Z-axis positioning). 0000 0000 0001 0000 16
XY-table acceleration/deceleration mode. Controls 0000 0000 0000 1000 8
the speed of the XY-table when it is moved to the
loading position and the board check position.
Do not perform D-axis premovement if there is a 0000 0000 0000 0100 4
block skip mark.
Change placement specifications according to 0000 0000 0000 0010 2
part height.
Skip nozzles which caused an error during nozzle 0000 0000 0000 0001 1
center measurement.
13: Machine_ID 0000 0000 0000 0000 *
This is one of the machine’s special operating parameters (input as a 16 bit binary mask
pattern).
Default: 0000 0000 0000 0000
Special mode Bit map Decimal
0603 (in. 0201) Parts Camera is used. 0000 0000 0000 0010 2
14: PCB_Location Corner: Pin #
This sets the method used to locate the board on the XY table.
Corner: Corner used as standard
Pin: Reference pin used as standard
When "Pin" is selected check to make sure that the reference pin is properly set in relation to
the board loaded onto the XY-table.
Default: "Corner”
20: Loader Status A 0000 0000 0000 0000 $
This sets board loader operating conditions (input as a 16 bit binary mask pattern).
Default: 0000 0000 0000 0000
Special mode Bit map Decimal
No IN1 Conveyor stopper 0000 0000 0010 0000 32
Use V 1.04 - Carry 0000 0000 0001 0000 16
Use V. 1.05 - Carry 0000 0000 0000 0000 0
21: Loader Status B 0000 0000 0000 0000 $
This sets board loader operating conditions (input as a 16 bit binary mask pattern).
Default: 0000 0000 0000 0000
22: Conveyor Type L -> R: R -> L *
This sets the direction of conveyor board flow.
L -> R: Left to right
R -> L: Right to left (Optional)
Default: L -> R.
23: Wait Signal Off: On $
This enables or disables the wait signal.
Default: "Off”
24: Busy Invalid No: Yes #
This is the setting for whether or not the machine refers to board request signals from the
previous stage.
No: Ignore board request signals and feed out boards when they become available.
Yes: Refer to board request signals
Default: "No”
25: Conveyor Control Manu: Auto #
This selects whether or not the conveyor width will be controlled automatically.
Manu: Manual conveyor adjustment
Auto: Automatic conveyor adjustment
Default: "Manu”
26: Conveyor Adj. Limit 0.05 ~ 1.00 [mm] #
This sets the limit to determine if fine adjustment of the conveyor width is required. Fine
adjustment is carried out if the difference between the current conveyor width and the
board width set in the program exceeds this limit.
Default: 0.50 mm
27: Conveyor Stop Offset 0.00 ~ 2.00 [mm] #
This sets the conveyor stop offset during conveyor width adjustment.
Default: 0.30 mm
28: Conveyor adj. Timer 0 ~ 120000 [msec] #
When performing automatic conveyor width adjustment this value sets the amount of time
that elapses before a time-up error occurs.
Default: 60000 msec
