Xmin/Ymin 532-5-0
Command Pass: [SET] - [PROPER] - [X/Y] - [Xmin/Ymin]
Press to set the Xmin/Ymin calibration results into Proper data.
Revision History
SET 532-1/3/4/5-1
Command Pass: [SET] - [PROPER] - [X/Y]
- [X0/Y0]/[XPCB/YPCB]/[Xmax/Ymax]/[Xmin/Ymin] - [SET]
Press to set the relevant Proper data.
Second Display Area
If start conditions are fulfilled, the message “Press START” flashes. Otherwise an error displays.
First Status Area
The relevant X0/Y0, XPCB/YPCB, Xmax/Ymax and Xmin/Ymin values are displayed here.
Revision History
V1.10 and later
D1/D2 533-0-0
Command Pass: [SET] - [PROPER] - [D1/D2]
Press to set Proper data for the D1- and D2-axes.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-93 CP643E System Reference
Pickup Pos. 533-1-0
Command Pass: [SET] - [PROPER] - [D1/D2] - [Pickup Pos.]
Press to set the standard parts pickup position in Proper data.
Revision History
V1.10 and later
PICKUP T1 533-1-1
Command Pass: [SET] - [PROPER] - [D1/D2] - [Pickup Pos.] - [PICKUP T1]
Press to set the pickup position T1 measurement results into Proper data.
Revision History
V1.10 and later
SET 533-1/2/3/4-1
Command Pass: [SET] - [PROPER] - [D1/D2] - [Pickup Pos.]/[ORIGIN]/[Max Limit]
/[Min Limit] - [SET]
Press to set the relevant Proper data.
Second Display Area
The message “Set Proper” will flash in green.
First Status Area
PICKUP T1, PICKUP T2, D1 ORIGIN, D2 ORIGIN, Z0, D1 max, D2 max, Z max, D1 min, D2 min, Z
min display here depending on what Proper data is being set.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-94 CP643E System Reference
PICKUP T2 533-1-2
Command Pass: [SET] - [PROPER] - [D1/D2] - [Pickup Pos.] - [PICKUP T2]
Press to set the pickup position T2 measurement results into Proper data.
Revision History
V1.10 and later
ORIGIN 533-2-0
Command Pass: [SET] - [PROPER] - [D1/D2] - [ORIGIN]
Press to set the D axes Resupply position in Proper data.
Revision History
V1.10 and later
D1 ORIGIN 533-2-1
Command Pass: [SET] - [PROPER] - [D1/D2] - [ORIGIN] - [D1 ORIGIN]
Press to set the D1 origin measurement results in Proper data.
Revision History
V1.10 and later
D2 ORIGIN 533-2-2
Command Pass: [SET] - [PROPER] - [D1/D2] - [ORIGIN] - [D2 ORIGIN]
Press to set the D2 origin measurement results in Proper data.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-95 CP643E System Reference
