3. OP Link OP Link Input 1 MX250 Address 0xef0280 LED No. No. Display Description A00 LX200 LOADER PLC OK Board loading sequencer functional A01 LX201 LOADER ALARM1 Board loader alarm 1 A02 LX202 LOADER ALARM2 Board load…

Board Loader PLC Output 1

LED No. No. Display Description

A00 LY000 PCB REQ OUT Board request signal to preceding stage

A01 LY001 PCB AVAIL OUT Board available signal to next stage

A02 LY002 IN CONVEYOR In-conveyor motor on

A03 LY003 IN REDUCE In-conveyor motor decelerated

A04 LY004 IN STPR UP In-conveyor stopper on

A05 LY005 IN STPR DWN In-conveyor stopper off

A06 LY006 IN2 STPR UP Out-conveyor stopper on

A07 LY007 IN2 STPR DWN Out-conveyor stopper off

A08 LY008 OUT CONVEYOR Out-conveyor motor on

A09 LY009 (Reserved)

A0A LY00A IN CRRY CLOSE In-carrier closed

A0B LY00B IN CRRY OPEN In-carrier open

A0C LY00C IN CRRY FWD In-carrier advanced

A0D LY00D IN CRRY BWD In-carrier retracted

A0E LY00E IN LFTR UP In-lifter lifted

A0F LY00F IN LFTR DWN In-lifter lowered

B00 LY010 ID CONV ON MCID conveyor motor on

B01 LY011 ID DECEL ON MCID conveyor motor decelerated

B02 LY012 ID REVERSE ON MCID conveyor motor reversed

B03 LY013 ID W.MOTOR ON MCID width adjustment motor operated

B04 LY014 ID W.MOTOR REV MCID width adjustment motor reversed

B05 LY015 ID STPR1 ON MCID forward rotation stopper on

B06 LY016 ID STPR2 ON MCID reverse rotation stopper on

B07 LY017 (Reserved)

B08 LY018 IN2 STPR UP IN Conveyor Stopper Up.

B09 LY019 IN2 STPR DN ED IN Conveyor Stopper Down.

B0A LY01A OUT CRRY CLOSE Out-carrier closed

B0B LY01B OUT CRRY OPEN Out-carrier open

B0C LY01C OUT CRRY FWD Out-carrier advanced

B0D LY01D OUT CRRY BWD Out-carrier retracted

B0E LY01E OUT LFTR UP Out-lifter lifted

B0F LY01F OUT LFTR DWN Out-lifter lowered

Part 6 Chapter 2 Loader I/O

Edition 1.1 6-2-4 CP643E System Reference

3. OP Link

OP Link Input 1 MX250 Address 0xef0280

LED No. No. Display Description

A00 LX200 LOADER PLC OK Board loading sequencer functional

A01 LX201 LOADER ALARM1 Board loader alarm 1

A02 LX202 LOADER ALARM2 Board loader alarm 2

A03 LX203 IN LDR CMPLT In-loader operation completed

A04 LX204 CLEAROFF CMPLT Board unloading completed

A05 LX205 PCB WAIT Awaiting next board

A06 LX206 NEXT WAIT Waiting for next stage available

A07 LX207 IN LDR WORK In-loader operated

A08 LX208 OUT LFTR UP ED Out-lifter upper limit

A09 LX209 OUT LFTR DN ED Out-lifter lower limit

A0A LX20A ID PCB OUT MCID board unloading completed

A0B LX20B ID PCB CHK1 MCID forward rotation board detection

A0C LX20C ID PCB CHK2 MCID reverse rotation board detection

A0D LX20D W.CONV PERMIT Conveyor width change permission

A0E LX20E LOADER ALARM3 Board loader alarm 3

A0F LX20F OUT CRRY FD ED Out-carrier advance end

B00 LX210 OUT1/2 PCB GAP Out-conveyor 1/2 board clearance

B01 LX211 IN1 REDUCED POS In-conveyor 1 board deceleration position

B02 LX212 IN2 REDUCED POS In-conveyor 2 board deceleration position

B03 LX213 IDLE TIME SIG Idling time measurement

B04 LX214 (Reserved)

B05 LX215 (Reserved)

B06 LX216 (Reserved)

B07 LX217 DATA SET COMP Data set completed

B08 LX218 LD I/O DATA0 I/O data 0

B09 LX219 LD I/O DATA1 I/O data 1

B0A LX21A LD I/O DATA2 I/O data 2

B0B LX21B LD I/O DATA3 I/O data 3

B0C LX21C LD I/O DATA4 I/O data 4

B0D LX21D LD I/O DATA5 I/O data 5

B0E LX21E LD I/O DATA6 I/O data 6

B0F LX21F LD I/O DATA7 I/O data 7

Part 6 Chapter 3 OP Link

Edition 1.0 6-3-1 CP643E System Reference

OP Link Input 2 MX250 Address 0xef02A0

LED No. No. Display Description

A00 LX220 PCB QTY TRRGR 1 Board supply quantity trigger 1

A01 LX221 PCB QTY TRRGR 2 Board supply quantity trigger 2

A02 LX222 FEED 1ST PCB First board supplied

A03 LX223 FEED 2ND PCB Second board supplied

A04 LX224 IN1 PCB CONF In-conveyor 1 board arrival

A05 LX225 IN2 PCB CONF In-conveyor 2 board arrival

A06 LX226 IN CRRY 1 PCB In-carrier 1 board detected

A07 LX227 IN CRRY 2 PCB In-carrier 2 board detected

A08 LX228 OUT CRRY 1 PCB Out-carrier 1 board detected

A09 LX229 OUT CRRY 2 PCB Out-carrier 2 board detected

A0A LX22A OUT1 PCB CONF Out-conveyor 1 board arrival

A0B LX22B OUT2 PCB CONF Out-conveyor 2 board arrival

A0C LX22C OUT PCB CONF Out conveyor board arrival

A0D LX22D OUT LDR WORK Out-loader operated

A0E LX22E OUT LDR CMPLT Out-loader operation completed

A0F LX22F FLAS OUT CMPLT Flashout completed

B00 LX230 IN LDR PCB TRG In-loader board presence trigger

B01 LX231 IN LDR NO PCB In-loader board not present

B02 LX232 PCB FEED OUT Board loading stopped / No board in machine

B03 LX233 OUT CRRY BE ED Out-carrier retract end

B04 LX234 OUT CRRY OPN FD Out-carrier open (advance side)

B05 LX235 OUT CRRY OPN BD Out-carrier open (retract side)

B06 LX236 OUTCRRY CLS FD Out-carrier closed (advance side)

B07 LX237 OUT CRRY CLS BD Out-carrier closed (retract side)

B08 LX238 IN LFTR UP END In-lifter upper end

B09 LX239 IN LFTR DN END In-lifter lower end

B0A LX23A IN CRRY FD END In-carrier advance end

B0B LX23B IN CRRY BD END In-carrier retract end

B0C LX23C IN CRRY OPN FD In-carrier open (advance side)

B0D LX23D IN CRRY OPN BD In-carrier open (retract side)

B0E LX23E IN CRRY CLS FD In-carrier closed (advance side)

B0F LX23F IN CRRY CLS BD In-carrier closed (retract side)

Part 6 Chapter 3 OP Link

Edition 1.0 6-3-2 CP643E System Reference
