TEMP. TRACE 522-4-2-5-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [TEMP. TRACE]
Each type of button can be set for graphically displaying a vision processing trace on the monitor
and for displaying the processing results.
Revision History
V1.10 and later
DISPLAY 522-4-2-5-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [DISPLAY]
This command is used to display the acquired image on the monitor.
Revision History
V1.10 and later
REINSPECT 522-4-2-5-4
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [REINSPECT]
Vision processing is performed again using the acquired image in order to check the cause and
vision processing trace of an error that has occurred.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-67 CP643E System Reference
DSP REAL-IMG 522-4-2-5-5
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [DSP REAL-IMG]
This is used to display the real image of the mark camera on the monitor.
Revision History
V1.10 and later
B MARK 522-4-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK]
This command is used to move the screen to the fiducial mark test processing commands.
Revision History
V1.10 and later
SET DATA 522-4-3-1
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK] - [SET DATA]
This sets the block skip mark used for carrying out test processing. Specify the sequence number.
Processing after numeric keypad input
If the numeric keypad is used to input a block skip mark sequence number that exists in the
production program stored in the foreground on the machine, the block skip mark of the specified
sequence will be vision processed.
After input is completed, each set value displays under the relevant item on the screen (“B/W”,
“Level”, “Size_x”, and “Size_y”) and the block skip mark applicable for test processing is
determined.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-68 CP643E System Reference
LEVEL SET 522-4-3-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK] - [LEVEL SET]
This command can be used to set the block skip mark threshold level.
The specified value after a change will be reflected in the production program.
Note: If F1 [SET DATA] has not been executed this command cannot be executed.
Revision History
V1.10 and later
SET SIZE 522-4-3-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK] - [SET SIZE]
This command can be used to set the block skip mark size. The specified value after a change will
be reflected in the production program.
Note: If F1 [SET DATA] has not been executed this command cannot be executed.
Processing after numeric keypad input
When a value from 0 to 999 is input using the numeric keypad, this input value becomes the set
block skip mark size.
Revision History
V1.10 and later
DSP REAL-IMG 522-4-3-4
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [B MARK] - [DSP REAL-IMG]
This is used to display the real image of the mark camera on the monitor.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-69 CP643E System Reference
