MODE 1 / MODE 2 / MODE 3 451-1/2/3-0
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3]
Press to select device check mode.
MODE 1: Press to display 10 consecutive devices regardless of whether each device is used or not.
MODE 2: Press to display only those devices that are to be used.
MODE 3: Press to display only those among the devices being used that have a condition such as
"Un Set", "Parts E", "Pickup", or "Vision".
First Display Area
The display will appear in accordance with the selected mode.
D001 Un Set [0013] Device_comment_No_1
D002 Parts E [0008] Korewa_No_2_Desu
D003 [0002] PCPR102TL
D004 [0000]
D005 Vision [0001] MSD2HD256
D006 Tape E [0005] Micro_Tr_No1
D007 Next_d [0007] Super_Mini_Tr
↑↑ ↑ ↑
(a) (b) (c) (d)
(a) : Device number
(b) : Parts status
Un Set (yellow display) : Parts not yet checked
Blank (green display) : Parts set
(blue display) : Device previously used is not to be used this time.
Next D (highlighted in blue) : Set as next device but not checked
Tape E (white display) : End of tape detected
Parts E (red display) : Out of parts
Pickup (highlighted in yellow) : Parts incorrectly picked up
Vision (purple) : Vision processing error
(c) : Number of parts per board
(d) : Device comment
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-32 CP643E System Reference
+PAGE 451-1/2/3-1
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [+PAGE]
Press to display the next page.
Revision History
-PAGE 451-1/2/3-2
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [-PAGE]
Press to display the previous page.
Revision History
▲ 451-1/2/3-3
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [▲]
Press to move the cursor up one line.
Revision History
▼ 451-1/2/3-4
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [▼]
Press to move the cursor down one line.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-33 CP643E System Reference
ESC 451-1/2/3-5
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [ESC]
Block check of all remaining unset parts.
This function is only enabled if the ESC_Permission Proper value is set to 1.
This function is not valid for devices on which the end of the tape has been detected.
The operation of this command varies according to the settings of the following Proper values.
Proper No. 71 Verifier_tool
Non: Handy Terminal is not used.
Proper No. 74 ESC_permission
Non: After a new program is selected, the [ESC] key is enabled in order to set all parts which
are currently not set.
Permit: The [ESC] key is disabled.
Proper No. 75 MAN_permission
Non: Input from the operation panel is enabled.
Permit: Input from the operation panel is disabled.
The [CR] Key and numerical keys are enabled when this Proper value is set to [Permit].
• If the device number is input from the numerical keypad followed by the [CR] key, the "Un Set",
"Next D", "Tape E", "Parts E", "Pickup", or "Vision" display for the input device number is cleared.
• If the cursor is moved to a device number using the function keys, the parts status display for
that device number can be cleared only by pressing the CR key.
Proper No. 70 Device_check_sw
Non: Device check does not start automatically when production begins.
Parts, Miss, Error: Device check starts automatically subject to the part data settings when
production begins. If the [RETURN] key is pressed before device check has
been completed, the machine enters the ‘Ready mode’ rather than enabling
the START button.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-34 CP643E System Reference
