Safety Guidelines
Edition 1.0 7 CP643E System Reference
3. Safety Rules for Individual Machine Types
CP-series Machines
WARNING
Do not reach into the machine over the rear fence
during operation.
● Body parts or clothing may be caught in the machine causing
personal injury.
Do not enter within the safety fence, even in cases of an
emergency stop.
● When an emergency stop occurs in step mode, power to the servo
amps is only cut after all axes have stopped moving. As a result,
there may be a short delay between the moment the emergency
arises and the power to the servo amps is cut.
● Do not enter the safety fence immediately following an emergency
stop, body parts or clothing may be caught in the machine causing
personal injury.
Do not operate the machine after removing the
transparent shutters from the D-axis.
● Body parts or clothing may be caught in the machine causing
personal injury.
Do not lean on the in- and out-conveyors during
operation.
● During operation do not lean on or across the in- and out-conveyors
to check the feeders.
Turn the power off when inspecting the cam box.
● When inspecting the upper part of the cam box, turn off the power
to the machine and exercise sufficient caution.
Safety Guidelines
Edition 1.0 8 CP643E System Reference
Make sure the cam is at its origin (0 deg.)
● Exercise extreme caution when working on the machine if the cam
is not at its origin (0 deg.). (The cam may not stop at its origin (0
deg.) in an emergency stop.) Recoil of the cam axis can endanger
the operator.
● If the cam is not at its origin (0 deg.), use a crank to rotate the cam
shaft until the indicator points to 0 degrees.
Do not stare into the laser beam.
● The CP-643E / CP-643ME is equipped with laser type
fiber sensors (class 2). Exercise extreme caution
when working in areas where there is a risk of eye
damage from the laser beams.
WARNING
4. Safety Labels
To warn the operator of hazards, safety labels are attached to the machine at the
positions indicated in the figure below.
Familiarize yourself with each label and its message before operating the machine.
Front Side of the Machine
Never insert your hand
inside an operating machine.
Moving parts may cause injury.
DANGER
3
6
8
9
10
Care should be taken
not to trap fingers
when opening/closing cover.
WARNING
7
4
<WARNING>
DISCONNECT POWER PRIOR TO SERVICING
5
Keep hands and
clothing well clear
of the moving conveyor
2
1
High Voltage
<CAUTION>
AN EXPLOSION MAY OCCUR IF THE BATTERY IS NOT REPLACED
PROPERLY. USE THE BATTERY TYPE SPECIFIED BY FUJI (OR
EQUIVALENT BATTERY TYPE).USED BATTERIES MUST BE
DISCARDED FOLLOWING THE MANUFACTURER'S INSTRUCTIONS.
m-064
Attention de ne pas se pincer
les doigts a l' ouverture/fermeture
des capots de protection
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS2 LASER PRODUCT
Maximum output
Pulse duration
Emitted wavelength
3mW
2.5µs
670nm
in conformity to IEC825 -1 11.1993
LASER RADIATION--
DO NOT STARE INTO BEAM
670nm
3.0mW
300µW
2.5µSEC
SEMICONDUCTOR LASER
MAXIMUM OUTPUT
(AVERAGE OUTPUT)
PULSE DURATION
CLASS II LASER PRODUCT
CAUTION
AVOID EXPOSURE
LASER RADIATION
IS EMITTED FROM
THIS APERTURE.
1
4
4
1
3
2
3
7
2
1
Same for left side
5
6
4
9,10
9,10
10
9
8
3
7
2
WARNING
THE BYPASS KEY OVERRIDES
SAFETY DOOR INTERLOCKS.
EXERCISE EXTREME CAUTIONEXERCISE EXTREME CAUTION
DURING USE
