MARK EDIT OR 130’-0-0 Command Pass: [AUTO] - [MARK EDITOR] Second Display Area When completing the necessary conditions: “Waiting for START” will display. When the conditions are not completed: An error message will disp…
AUTO 100-0-0
Command Pass: [AUTO]
The automatic production is performed.
Revision History
Cam Org Pos 120-0-0
Command Pass: [AUTO] - [Cam Org Pos]
Press to return cam axis to its origin position. While this key remains pressed the cam will move
toward its origin position. Movement stops when the cam returns to its origin. Movement also
stops if the key is released before the cam reaches its origin.
The message “Return Cam to Zero” displays in the second display area until the cam reaches its
origin. When the cam has returned the message “Press START” displays.
Revision History
MARK EDITOR 130-0-0
Command Pass: [AUTO] - [MARK EDITOR]
This command is used to edit the fiducial mark.
If there is not a fiducial sequence in the production program, this cannot be used.
Input the desired sequence number using the numeric keypad.
If the sequence number input has been entered the display goes to command page 130’.
Caution: This is a help command for irregular marks. If the mark sequence coordinates are obviously wrong
then revise the production program and then transmit the program again from the host computer.
Operators should also be aware beforehand that if this command is used the placing accuracy may
not fall within the accuracy range guaranteed by Fuji.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-2 CP643E System Reference
MARK EDITOR 130’-0-0
Command Pass: [AUTO] - [MARK EDITOR]
Second Display Area
When completing the necessary conditions: “Waiting for START” will display.
When the conditions are not completed: An error message will display.
When the START button is pressed
Pressing the START button will move the board so that the selected fiducial mark is under the mark
read camera (movement is based on the coordinates specified by the user).
Revision History
SET DATA 130''-1-0
Command Pass: [AUTO] - [MARK EDITOR] - [SET DATA]
This function key is used to manually set the fiducial mark coordinates. When this key is pushed,
the difference between the fiducial mark coordinates and the current position coordinates become
the correction factor. This key will not display if all the marks are being read correctly.
When it is necessary to revise the current position, adjust using the inching key and then push this
button.
When this difference is larger than the camera's field of vision, this will be displayed as an "Input
Error". When the data is being set, "Set Data" will display on the screen.
When the operator wants to release the value that was input manually, if the key is pushed again
the value is released and the expression "Set Data" will disappear.
If Automatic production is then entered , the mark will be processed.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-3 CP643E System Reference
SKIP 130''-2-0
Command Pass: [AUTO] - [MARK EDITOR] - [SKIP]
This key is used so that the fiducial mark can be set to skip. When this key is pushed, the fiducial
mark is skipped and the image that was displayed on the screen is now processed as data .
If trying to skip a mark that has not been processed once, because important data is not recorded, an
alarm stating that the command is not recognized will display.
When the skip function is being used, "Skip" will display on the screen. After using the "SKIP" key,
the "CANCEL" key will display. When the operator wants to release from the skip mode, push the
"CANCEL" key. If Automatic production is then entered, that mark will be processed.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
BRIGHT 130''-4-0
Command Pass: [AUTO] - [MARK EDITOR] - [BRIGHT]
This key is used when camera offset and/or gain needs to be changed. To command page 522-2.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-4 CP643E System Reference
