HT REST (Displayed for Handy Terminal) 524-1-0

Command Pass: [SET] - [MANUAL] - [HT] - [HT RESET]

If the Handy Terminal hangs up for some reason then this key can be pressed to reset or reinitialize

the Handy Terminal.

Revision History

BC TEST (Displayed for Handy Terminal) 524-2-0

Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST]

Press to carry out a bar code read test.

Revision History

HT RESET (Displayed for Handy Terminal) 524-2-1

Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST] - [HT RESET]

This command is not available during the BC TEST processing.

Revision History

CODE READ (Displayed for Handy Terminal) 524-2-2

Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST] - [CODE READ]

When this key is pressed it becomes possible for the Handy Terminal to read bar codes. When a

code is read it will display as shown above. If the type of bar code changes it is possible to check to

see if the new code can be read.

Revision History

Part 3 Chapter 3 Command Descriptions

Edition 1.0 3-3-81 CP643E System Reference

PROPER 530-0-0

Command Pass: [SET] - [PROPER]

Press to make Proper Data measurements. To use this command the operator must enter an ID

code.

Revision History

CAMERA 531-0-0

Command Pass: [SET] - [PROPER] - [CAMERA]

Press to set camera related Proper data.

Revision History

XC/YC 531-1-0

Command Pass: [SET] - [PROPER] - [CAMERA] - [XC/YC]

Press to measure the mark camera reading position.

Revision History

SET 531-1-1

Command Pass: [SET] - [PROPER] - [CAMERA] - [XC/YC] - [SET]

Press to set the present position for the XY-table as Mark Read Pos. XC/YC.

Caution: Before performing this command, move the XY-table to the center position of the mark setting jig.

After performing this command, make sure to perform mark camera position measurement and

camera tilt measurement (command page 531-2).

Revision History

Part 3 Chapter 3 Command Descriptions

Edition 1.0 3-3-82 CP643E System Reference

Z0 531-1-3

Command Pass: [SET] - [PROPER] - [CAMERA] - [XC/YC] - [Z0]

Press to move the Z-axis to Origin Position Z in Proper data.

Revision History

SPEED 531-1-5

Command Pass: [SET] - [PROPER] - [CAMERA] - [XC/YC] - [SPEED]

Press to set the inching speeds of the axes.

Revision History

MARK 531-2-0

Command Pass: [SET] - [PROPER] - [CAMERA] - [MARK]

Press to measure the mark camera resolution, tilt (X ,Y direction) and rotation.

Caution: Use this command after measuring the camera XC/YC Proper data while the mark jig remains directly

below the Mark camera. These settings are machine Proper data settings and thus it is necessary to

transmit Proper data to the host computer once Proper data measurement is completed.

Revision History

WIDE 531-3-0

Command Pass: [SET] - [PROPER] - [CAMERA] - [WIDE]

Press to measure the resolution, tilt (X ,Y direction) and rotation of the wide view parts camera.

Revision History

Part 3 Chapter 3 Command Descriptions

Edition 1.0 3-3-83 CP643E System Reference
