▲ 523-2-3 Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [ ▲ ] Press to move the cursor up one line. Revision History ▼ 523-2-4 Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [ ▼ ] Press to move…
+NOZZLE 523-1-5-1/2-2-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE]/[NARROW] - [BACKLIGHT DATA] - [+NOZZLE]
Press to increase the nozzle number of the results being displayed by one. The nozzle following
nozzle 6 is nozzle 1.
Revision History
-NOZZLE 523-1-5-1/2-2-4
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [CENTER] - [DISPLAY]
- [WIDE] / [NARROW] - [BACKLIGHT DATA] - [-NOZZLE]
Press to decrease the nozzle number of the results being displayed by one. The nozzle following
nozzle 1 is nozzle 6.
Revision History
NOZZLE SKIP 523-2-0
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [NOZZLE SKIP]
Enables nozzles to be skipped manually.
Revision History
NOZZLE TYPE 523-2-1
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [NOZZLE TYPE]
Press to choose from nozzle 1~6.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-79 CP643E System Reference
▲ 523-2-3
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [▲]
Press to move the cursor up one line.
Revision History
▼ 523-2-4
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [▼]
Press to move the cursor down one line.
Revision History
SKIP/CLEAR 523-2-5
Command Pass: [SET] - [MANUAL] - [NOZZLE] - [SKIP NOZZLE] - [SKIP/CLEAR]
Align the cursor with the desired nozzle and press this key to manually set the nozzle to be
skipped. "SKIP" will display in yellow beside the nozzle. Use the same key to cancel the skip
setting. When the cursor is set at a nozzle which has been set to be skipped, the command will
change to “CLEAR”.
Revision History
HT (Displayed for Handy Terminal) 524-0-0
Command Pass: [SET] - [MANUAL] - [HT]
Press to enter commands related to the Handy Terminal.
An ID code is necessary for entering this command. This command will not appear if the Handy
Terminal option is not used.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-80 CP643E System Reference
HT REST (Displayed for Handy Terminal) 524-1-0
Command Pass: [SET] - [MANUAL] - [HT] - [HT RESET]
If the Handy Terminal hangs up for some reason then this key can be pressed to reset or reinitialize
the Handy Terminal.
Revision History
BC TEST (Displayed for Handy Terminal) 524-2-0
Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST]
Press to carry out a bar code read test.
Revision History
HT RESET (Displayed for Handy Terminal) 524-2-1
Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST] - [HT RESET]
This command is not available during the BC TEST processing.
Revision History
CODE READ (Displayed for Handy Terminal) 524-2-2
Command Pass: [SET] - [MANUAL] - [HT] - [BC TEST] - [CODE READ]
When this key is pressed it becomes possible for the Handy Terminal to read bar codes. When a
code is read it will display as shown above. If the type of bar code changes it is possible to check to
see if the new code can be read.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-81 CP643E System Reference
