PCB LD / UNLD 532-2-0 Command Pass: [SET] - [PROPER] - [X/Y] - [PCB LD / UNLD] This is used to set the XL_OUT/YL_OUT or XL_IN/YL_IN measurement results in Proper data. Revision History V1.10 and later UNLOAD POS. 532-2-1…
SELECT 531-5-2/3-5
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT]
- [WIDE]/[NARROW] - [SELECT]
Press to switch between the type of setting (i.e.gain or offset).
Caution: The gain and offset levels set here are machine Proper data settings and thus it is necessary to
transmit Proper data to the host computer once Proper data measurement is completed.
Revision History
NARROW 531-5-3
Command Pass: [SET] - [PROPER] - [CAMERA] - [BRIGHT] - [NARROW]
Press to set the parts camera (narrow view) gain and offset.
Revision History
X/Y 532-0-0
Command Pass: [SET] - [PROPER] - [X/Y]
Press to set Proper data for the X- and Y-axes.
Revision History
X0/Y0 532-1-0
Command Pass: [SET] - [PROPER] - [X/Y] - [X0/Y0]
Press to set the X0/Y0 calibration results into Proper data.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-90 CP643E System Reference
PCB LD / UNLD 532-2-0
Command Pass: [SET] - [PROPER] - [X/Y] - [PCB LD / UNLD]
This is used to set the XL_OUT/YL_OUT or XL_IN/YL_IN measurement results in Proper data.
Revision History
V1.10 and later
UNLOAD POS. 532-2-1
Command Pass: [SET] - [PROPER] - [X/Y] - [PCB LD / UNLD] - [UNLOAD POS.]
This is used to set the XL_OUT/YL_OUT measurement results in Proper data.
Revision History
V1.10 and later
LOAD POS. 532-2-2
Command Pass: [SET] - [PROPER] - [X/Y] - [PCB LD / UNLD] - [LOAD POS.]
This is used to set the XL_IN/YL_IN measurement results in Proper data.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-91 CP643E System Reference
SET 532-2-1/2-5
Command Pass: [SET] - [PROPER] - [X/Y] - [PCB LD / UNLD] - [UNLOAD POS.] / [LOAD POS.]
- [SET]
This command sets the value in the relevant Proper data item.
Second display area
When the start conditions are satisfied, the message “Set Proper.” will flash in green in this display
area. In all other cases an error will display.
First status area
Either “UNLOAD POS.” or “LOAD POS.” will display, whichever is relevant.
Revision History
V1.10 and later
XPCB/YPCB 532-3-0
Command Pass: [SET] - [PROPER] - [X/Y] - [XPCB/YPCB]
Press to set the XPCB/YPCB calibration results into Proper data.
Revision History
Xmax/Ymax 532-4-0
Command Pass: [SET] - [PROPER] - [X/Y] - [Xmax/Ymax]
Press to set the Xmax/Ymax calibration results into Proper data.
Revision History
Part 3 Chapter 3 Command Descriptions
