Z 535-0-0
Command Pass: [SET] - [PROPER] - [Z]
This is used to measure the Z-axis Proper data.
Revision History
V1.10 and later
ZL 535-1-0
Command Pass: [SET] - [PROPER] - [Z] - [ZL]
This is used for setting the Z-axis loading and unloading height.
Revision History
V1.10 and later
ZL_OUT 535-1-1
Command Pass: [SET] - [PROPER] - [Z] - [ZL] - [ZL_OUT]
This sets the Z-axis unloading height.
Revision History
V1.10 and later
ZL_IN 535-1-2
Command Pass: [SET] - [PROPER] - [Z] - [ZL] - [ZL_IN]
This sets the Z-axis loading height.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-100 CP643E System Reference
SET 535-1-1/2-1
Command Pass: [SET] - [PROPER] - [Z] - [ZL] - [ZL_OUT] / [ZL_IN] - [SET]
This command sets the measured value in the relevant Proper data item.
Second display area
The message “Set Proper” will flash in green in this display area.
First status area
“ZL_OUT”, “ZL_IN”, “Z0”, Zmax”, “Zmin” or “M_load_Pos” will display, whichever is relevant.
Revision History
V1.10 and later
Z0 535-2-0
Command Pass: [SET] - [PROPER] - [Z] - [Z0]
This measures the “Z0” Proper data.
Revision History
V1.10 and later
Zmax 535-3-0
Command Pass: [SET] - [PROPER] - [Z] - [Zmax]
This sets the Z-axis positive direction Proper data item.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-101 CP643E System Reference
Zmin 535-4-0
Command Pass: [SET] - [PROPER] - [Z] - [Zmin]
This sets the Z-axis negative direction Proper data item.
Revision History
V1.10 and later
M_load_pos 535-5-0
Command Pass: [SET] - [PROPER] - [Z] - [M_load_pos]
This sets the “M_load_pos” Proper data.
Revision History
V1.10 and later
SERVO 540-0-0
Command Pass: [SET] - [SERVO]
Press to set servo parameters.
The servo counter is automatically displayed when the command [SERVO] is selected.
Caution : Holding down the inching shift key ([F]) while pressing RETURN will cause the servo counter display
to remain on the monitor.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-102 CP643E System Reference
