CHANGE 522-3-1-1-3 Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ.] - [CHANGE] This command is used to change the camera type or light source type that is used for image acquisition. Cam…
ADJUST 522-3-0
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT]
Commands related to camera adjustment are grouped together under the [ADJUSTMENT]
command.
Revision History
V1.10 and later
GET ACQ 522-3-1
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.]
The [GET ACQ.] command can be used to adjust the camera focus and image brightness, and to
verify the status of an acquired image.
Revision History
V1.10 and later
GET ACQ 522-3-1-1
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ]
This command is used to acquire an image. The camera and light source can also be set from this
command.
Revision History
V1.10 and later
▲ / ▼ 522-3-1-1-3-1/2
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ]
[CHANGE] - [▲ / ▼]
This command is used to select the camera or light source type.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-62 CP643E System Reference
CHANGE 522-3-1-1-3
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ.]
- [CHANGE]
This command is used to change the camera type or light source type that is used for image
acquisition.
Camera · Light source selection
Align the cursor with the camera or light source to be used for image acquisition and press
RETURN to select.
This display is the screen display for carrying out camera selection.
This display is the screen display for carrying out light source selection.
Revision History
V1.10 and later
▲▼
CP643S3020
RETURN
SELECT LIGHT SOURCE
Page 522
Select No.
1. Back Light
2. Front Light
▲▼
CP643S3019
RETURN
SELECT CAMERA
Page 522
Select No.
1. Mark Camera
2. Wide View Camera
3. Narrow View Camera
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-63 CP643E System Reference
DSP REAL-IMG 522-3-1-1-5
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ.]
- [DSP REAL-IMG]
This command displays the actual part camera image on the monitor.
Revision History
V1.10 and later
VISION TEST 522-4-0
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST]
Under the [VISION TEST] command there is a fiducial mark vision processing command and a
block skip mark vision processing command.
Revision History
V1.10 and later
F MARK 522-4-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK]
This moves the display to the fiducial mark test processing commands.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-64 CP643E System Reference
