Notes: Part 6 Chapter 4 Servo Board Edition 1.0 6-4-4 CP643E System Reference
Servo Input 3 (D1, D2, NC axes)
No. Display Description
SX020 NO3 EMERGENCY No. 3 servo board emergency stop input
SX021 Currently not in use
SX022 Currently not in use
SX023 Currently not in use
SX024 D1 AXIS +OT D1 axis overtravel (+)
SX025 D1 AXIS -OT D1 axis overtravel (-)
SX026 D1 AXIS ZERO D1 axis zero setting sensor
SX027 D1 AXIS READY D1 axis interlock
SX028 D2 AXIS +OT D2 axis overtravel (+)
SX029 D2 AXIS -OT D2 axis overtravel (-)
SX02A D2 AXIS ZERO D2 axis zero setting sensor
SX02B D2 AXIS READY D2 axis interlock
SX02C Currently not in use
SX02D Currently not in use
SX02E NC AXIS ZERO NC axis zero setting sensor
SX02F Currently not in use
Part 6 Chapter 4 Servo Board
Edition 1.0 6-4-3 CP643E System Reference
Notes:
Part 6 Chapter 4 Servo Board
Edition 1.0 6-4-4 CP643E System Reference
CP-643E/643ME System Reference Manual
Edition 1.0 March 10, 2000
Edition 1.1 January 15, 2001
FUJI Machine Manufacturing Co., Ltd.
SMT Equipment
19 Chausuyama, Yamamachi, Chiryu,
Aichi Prefecture, 472-8686 Japan
Copyright 2001 by Fuji Machine Manufacturing Co., Ltd.
Printed in Japan
The FUJI Internet
Fuji Internet aims at providing information to our customers in
the most efficient manner. This site makes a range of services
available, from manual updates and FAQs, to online technical
reports. Fuji hopes that this site will be used as a source of
information in addition to the services provided by your agent.
Fuji’s website is located at http://smt.fuji.co.jp/
Fuji Internet membership is required to access the Technical
Information section of the site, contact your agent for details.
