MARK EDITOR 130’-0-0
Command Pass: [AUTO] - [MARK EDITOR]
Second Display Area
When completing the necessary conditions: “Waiting for START” will display.
When the conditions are not completed: An error message will display.
When the START button is pressed
Pressing the START button will move the board so that the selected fiducial mark is under the mark
read camera (movement is based on the coordinates specified by the user).
Revision History
SET DATA 130''-1-0
Command Pass: [AUTO] - [MARK EDITOR] - [SET DATA]
This function key is used to manually set the fiducial mark coordinates. When this key is pushed,
the difference between the fiducial mark coordinates and the current position coordinates become
the correction factor. This key will not display if all the marks are being read correctly.
When it is necessary to revise the current position, adjust using the inching key and then push this
button.
When this difference is larger than the camera's field of vision, this will be displayed as an "Input
Error". When the data is being set, "Set Data" will display on the screen.
When the operator wants to release the value that was input manually, if the key is pushed again
the value is released and the expression "Set Data" will disappear.
If Automatic production is then entered , the mark will be processed.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-3 CP643E System Reference
SKIP 130''-2-0
Command Pass: [AUTO] - [MARK EDITOR] - [SKIP]
This key is used so that the fiducial mark can be set to skip. When this key is pushed, the fiducial
mark is skipped and the image that was displayed on the screen is now processed as data .
If trying to skip a mark that has not been processed once, because important data is not recorded, an
alarm stating that the command is not recognized will display.
When the skip function is being used, "Skip" will display on the screen. After using the "SKIP" key,
the "CANCEL" key will display. When the operator wants to release from the skip mode, push the
"CANCEL" key. If Automatic production is then entered, that mark will be processed.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
BRIGHT 130''-4-0
Command Pass: [AUTO] - [MARK EDITOR] - [BRIGHT]
This key is used when camera offset and/or gain needs to be changed. To command page 522-2.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-4 CP643E System Reference
SPEED 130''-5-0
Command Pass: [AUTO] - [MARK EDITOR] - [SPEED]
This is used when slight changes or adjustments of the current position are required.
To command page 541.
Caution: The changes that were set while in the Mark Editor Mode, such as Mark Sequence Skip or other
manual input, are only valid for the board that is being produced. After that board production is
finished and the board has been unloaded, the machine automatically releases those settings and the
following boards will be produced under normal settings. Also, if a condition arises where it becomes
necessary to read that fiducial mark, it will be necessary to read the mark that was set to be skipped.
Revision History
RETURN 130''-6-0
Command Pass: [AUTO] - [RETURN]
This is used when wanting to exit Mark Editor. The cross hairs displayed on the screen disappear
and Editor is exited after the previous changes have been saved.
Revision History
SEQ. NO 140-0-0
Command Pass: [AUTO] - [SEQ. NO]
Press to input the sequence number from which operation is to be started.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-5 CP643E System Reference
