CHANGE 522-3-1-1-3
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ.]
- [CHANGE]
This command is used to change the camera type or light source type that is used for image
acquisition.
Camera · Light source selection
Align the cursor with the camera or light source to be used for image acquisition and press
RETURN to select.
This display is the screen display for carrying out camera selection.
This display is the screen display for carrying out light source selection.
Revision History
V1.10 and later
▲▼
CP643S3020
RETURN
SELECT LIGHT SOURCE
Page 522
Select No.
1. Back Light
2. Front Light
▲▼
CP643S3019
RETURN
SELECT CAMERA
Page 522
Select No.
1. Mark Camera
2. Wide View Camera
3. Narrow View Camera
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-63 CP643E System Reference
DSP REAL-IMG 522-3-1-1-5
Command Pass: [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [GET ACQ.]
- [DSP REAL-IMG]
This command displays the actual part camera image on the monitor.
Revision History
V1.10 and later
VISION TEST 522-4-0
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST]
Under the [VISION TEST] command there is a fiducial mark vision processing command and a
block skip mark vision processing command.
Revision History
V1.10 and later
F MARK 522-4-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK]
This moves the display to the fiducial mark test processing commands.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-64 CP643E System Reference
SET DATA 522-4-2-1
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [SET DATA]
This sets the fiducial mark used for carrying out test processing. Specify the sequence number.
Processing after numeric keypad input
If the numeric keypad is used to input a fiducial mark sequence number that exists in the
production program stored in the foreground on the machine, each type of data (camera, scan area,
fiducial mark ID) must be set so that the fiducial mark of the specified sequence can be vision
processed.
After input is completed, each set value displays under the relevant item on the screen (“Pattern”,
“B/W”, Size_a”, “Size_b”, “Size_c”, and “Scan”) and the fiducial mark applicable for test
processing is determined.
Revision History
V1.10 and later
TEMP. TRACE 522-4-2-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [TEMP. TRACE]
Each type of button can be set so that a vision processing trace and the results of vision processing
are graphically displayed on the monitor.
Revision History
V1.10 and later
DSP REAL-IMG 522-4-2-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [DSP REAL-IMG]
This command can be used to display the actual mark camera image on the monitor. If this
command is selected the fiducial camera light comes on and the actual image is acquired.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-65 CP643E System Reference
