VISION 522-0-0
Command Pass: [SET] - [MANUAL] - [VISION]
Press to make various adjustments to the vision processing system.
The user must input an ID code to enter this mode.
Revision History
BUFFER IMG 522-1-0
Command Pass : [SET] - [MANUAL] - [VISION] - [BUFFER IMG]
In the [BUFFER IMG] command page there are commands for displaying the images that are saved
on the vision processing board and a command for vision processing images again.
These commands can be used when a vision processing error occurs during production in order to
check the image, vision process the image again, and otherwise help find the cause of the error. Up
to three acquired images can be saved.
Revision History
V1.10 and later
REINSPECT 522-1-1
Command Pass : [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [REINSPECT]
The [REINSPECT] command takes the image corresponding to the image number currently selected
and uses the contents that were processed when the image was acquired to vision process the image
again.
The vision processing results are displayed in the bottom portion of the first display area.
Images that can be reinspected include vision processed parts and fiducial marks. Images acquired
in any other process cannot be reinspected.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-51 CP643E System Reference
TEMP. TRACE 522-1-2
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [TEMP. TRACE]
The [TEMP. TRACE] command is used to carry out trace settings for graphically displaying the
vision processing trace.
Refer to the explanation of the [TRACE] command regarding the details of these trace settings.
Revision History
V1.10 and later
SEL BUF IMG 522-1-3
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [SEL BUF IMG]
The [SEL BUF IMG] command is used to toggle between the image numbers.
The toggled image number is selected and the image becomes the relevant image for reinspection or
display.
Revision History
V1.10 and later
DISPLAY 522-1-4/522-3-1-2
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY]
/[SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY]
This command displays the buffer image or acquired image on the vision processing monitor. In
addition, it changes the screen to the command page that displays commands used for zooming in,
zooming out, and scrolling the image.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-52 CP643E System Reference
ZOOM IN 522-1-4-1/522-3-1-2-1
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [ZOOM IN] / [SET]
- [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY] - [ZOOM IN]
This command magnifies the image that is displayed on the vision processing monitor. The image
is magnified further each time the function key is pressed. The maximum magnification rate is 128
times.
A magnified image can be used to verify a portion of an image that cannot be confirmed with the
focus and gray scale value per pixel of the normal monitor display.
Revision History
V1.10 and later
ZOOM OUT 522-1-4-2/522-3-1-2-2
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [ZOOM OUT]
/ [SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY]
- [ZOOM OUT]
This command reduces the image that is displayed on the vision processing monitor. The image is
reduced further each time the function key is pressed. The maximum magnification rate is 1/128
times. This zooming out function can be used to return a magnified image to its original size or to
check the entire image.
Note: An image cannot be reduced further than the image size originally acquired by the CCD camera.
Revision History
V1.10 and later
SCROLL 522-1-4-4/522-3-1-2-4
Command Pass: [SET] - [MANUAL] - [VISION] - [BUFFER IMG] - [DISPLAY] - [SCROLL]
/[SET] - [MANUAL] - [VISION] - [ADJUSTMENT] - [GET ACQ.] - [DISPLAY]
- [SCROLL]
In the [SCROLL] command the direction of movement (up, down, left or right) changes each time
the function key is pressed. In the case of a magnified image, the [SCROLL] command can be used
to display one portion of the image in order to check that portion.
Revision History
V1.10 and later
