ESC 451-1/2/3-5 Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [ESC] Block check of all remaining unset parts. This function is only enabled if the ESC_Permission Proper value is set to 1. This functio…
+PAGE 451-1/2/3-1
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [+PAGE]
Press to display the next page.
Revision History
-PAGE 451-1/2/3-2
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [-PAGE]
Press to display the previous page.
Revision History
▲ 451-1/2/3-3
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [▲]
Press to move the cursor up one line.
Revision History
▼ 451-1/2/3-4
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [▼]
Press to move the cursor down one line.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-33 CP643E System Reference
ESC 451-1/2/3-5
Command Pass: [PROGRAM] - [DEVICE] - [CHECK] - [MODE 1 / 2 / 3] - [ESC]
Block check of all remaining unset parts.
This function is only enabled if the ESC_Permission Proper value is set to 1.
This function is not valid for devices on which the end of the tape has been detected.
The operation of this command varies according to the settings of the following Proper values.
Proper No. 71 Verifier_tool
Non: Handy Terminal is not used.
Proper No. 74 ESC_permission
Non: After a new program is selected, the [ESC] key is enabled in order to set all parts which
are currently not set.
Permit: The [ESC] key is disabled.
Proper No. 75 MAN_permission
Non: Input from the operation panel is enabled.
Permit: Input from the operation panel is disabled.
The [CR] Key and numerical keys are enabled when this Proper value is set to [Permit].
• If the device number is input from the numerical keypad followed by the [CR] key, the "Un Set",
"Next D", "Tape E", "Parts E", "Pickup", or "Vision" display for the input device number is cleared.
• If the cursor is moved to a device number using the function keys, the parts status display for
that device number can be cleared only by pressing the CR key.
Proper No. 70 Device_check_sw
Non: Device check does not start automatically when production begins.
Parts, Miss, Error: Device check starts automatically subject to the part data settings when
production begins. If the [RETURN] key is pressed before device check has
been completed, the machine enters the ‘Ready mode’ rather than enabling
the START button.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-34 CP643E System Reference
OFFSET 455-0-0
Command Pass: [PROGRAM] - [DEVICE] - [OFFSET]
Press to set device offset for any device in the current program.
First Display Area
[Example]
DEVICE OFFSET Editor
D No. Proper DATA Part DATA Auto Rev.
D001 00.000 [mm] 00.0 [mm] 00.000 [mm]
D002 00.000 [mm] 00.0 [mm] 00.000 [mm]
D003 00.000 [mm] 00.0 [mm] 00.000 [mm]
D004 00.000 [mm] **** [mm] ****** [mm]
D005 00.000 [mm] **** [mm] ****** [mm]
D006 00.000 [mm] 00.0 [mm] 00.000 [mm]
D007 00.000 [mm] 00.0 [mm 00.000 [mm]
D008 00.000 [mm] 00.0 [mm] 00.000 [mm]
D009 00.000 [mm] **** [mm] ****** [mm]
D010 00.000 [mm] **** [mm] ****** [mm]
No.: Device number
Proper Data: The Proper data settings for Device Offset 1 ~ Device Offset 140 are displayed here.
These settings can be entered directly at the machine.
Part Data: The Part data settings in Pickup_offset are displayed here. The asterisks (******)
indicate that the device is not being used. These settings cannot be entered directly
at the machine.
Auto Rev.: The amount of automatic offset is displayed here. The asterisks (******) indicate that
the device is not being used. These settings cannot be entered directly at the
machine.
Revision History
+PAGE 455-1-0
Command Pass: [PROGRAM] - [DEVICE] - [OFFSET] - [+PAGE]
Press to display the next page.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-35 CP643E System Reference
