Part 4 Proper Data

Notes :

Part 3 Chapter 4 Supplement

Edition 1.0 3-4-2 CP643E System Reference

Part 4 Proper Data

1. Proper Data Listing

A list of the Proper data items that are used by the CP-643E is provided in the table below.

The symbols listed before each of the Proper data items have the following meanings.

✩ : Varies from machine to machine. Must be measured.

* : Cannot be changed by the user.

# : Can be changed by the user.

@ : Machine automatically changes this. (Sometimes the user can also change this).

$ : Not currently in use.

DATA NAME INPUT RANGE

# 1: ID_Code ASCII CODE = ~

# 2: Language = [English] Japanese French

# 3: Red_Light = 0000 0100 0000 0000

# 4: Yellow_Light = 0000 0000 0010 0100

# 5: Blue_Light = 0000 0011 0000 0000

# 6: Red_Flash = 0000 0000 0000 1000

# 7: Yellow_Flash = 0010 0000 0001 0010

# 8: Blue_Flash = 0000 1000 1100 0001

$# 9: User_Define A = 0000 0000 0000 0000

* 11: Machine_Status A = 0000 0000 0000 0000

# 12: Machine_Status B = 0000 0000 0000 0000

* 13: Machine_ID = 0000 0000 0000 0000

# 14: PCB_Location = [Corner] Pin

$ 20: Loader Status A = 0000 0000 0000 0000

$ 21: Loader Status B = 0000 0000 0000 0000

* 22: Conveyor Type = [L->R] R->L

$ 23: Wait Signal = [Off] On

# 24: Busy Invalid = [No] Yes

# 25: Conveyor Control = [Manu] Auto

# 26: Conveyor Adj. Limit (0.05~1.00) [mm] = 0.50

# 27: Conveyor Stop Offset (0.00~2.00) [mm] = 0.30

# 28: Conveyor adj. Timer (0~120000) [msec] = 60000

* 29: Width Max Limit (0.00~655.35) [mm] = 460.00

* 30: Width Min Limit (0.00~655.35) [mm] = 50.00

# 40: LMS Flag = [Off] On

# 41: Cell Status = [Unit] Active Passive

# 42: Change Over Mode (0~200) = 000

$# 43: Auto Start = [No] Yes

# 44: Backup Plate Check = [No] Yes

* 45: Command Line Status = [RS232C] LAN ETHERNET

# 46: Command Line Port (0~30) = 00

* 47: ID Station Type = [S_type] A_type

# 48: Buzzer Warning = [On] Off

# 49: Process Timer (1~120000) [msec] = 10000

# 50: Reader Type (0~9) = 0

# 51: Code Reader Timer (1~120000) [msec] = 10000

# 52: Code Reader Retry (0~10) = 00

# 53: Reader1 Port No. (0~30) = 00

# 54: Reader2 Port No. (0~30) = 00

# 55: PCB Code Terminal = [Non] Use
