CHANGE 410-0-0
Command Pass: [PROGRAM] - [CHANGE]
Press to change the production program.
Input program number using numerical keypad.
• Changeover will take place if an input program number has been existed.
• When changeover takes place the data necessary for placing parts will be processed and the
message "Calculating Placing Data" will display.
Revision History
QTY. SET 420-0-0
Command Pass: [PROGRAM] - [QTY. SET]
Press to change the scheduled production quantity.
Input from the numerical keypad the number of boards to be produced under the current
production program.
Enter a number between 1 and 65,000. When the number of boards produced reaches the scheduled
production quantity the machine quits automatic operation and the RESET button is enabled. If the
scheduled production quantity is set to “0” this will be judged as no scheduled quantity and
production will continue indefinitely.
Production will continue indefinitely if a value of 0 is entered.
The display then returns to command page 400.
Revision History
QTY. CLEAR 430-0-0
Command Pass: [PROGRAM] - [QTY. CLEAR]
Press to clear the completed production quantity to zero.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-29 CP643E System Reference
SKIP 440-0-0
Command Pass: [PROGRAM] - [SKIP]
Press to set the block skip function.
Revision History
BLOCK 441-0-0
Command Pass: [PROGRAM] - [SKIP] - [BLOCK]
Press to set or clear the block skip setting.
First Display Area
"P" indicates block for normal production and "S" indicates block to be skipped.
Blocks displayed in red have been set in program to be skipped.
Input the number of the block to be skipped by using numerical keypad.
If the block was set to be produced, it will now be skipped, and vice versa.
Caution: A block skip set in program can only be cleared by changing the program and retransmitting it to the
machine.
Revision History
+PAGE 441-1-0
Command Pass: [PROGRAM] - [SKIP] - [BLOCK] - [+PAGE]
Press to display the next page if a program contains more than 40 blocks.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-30 CP643E System Reference
-PAGE 441-2-0
Command Pass: [PROGRAM] - [SKIP] - [BLOCK] - [-PAGE]
Press to display the previous page if a program contains more than 40 blocks.
Revision History
DEVICE 450-0-0
Command Pass: [PROGRAM] - [DEVICE]
Press to make device related settings.
Revision History
CHECK 451-0-0
Command Pass: [PROGRAM] - [DEVICE] - [CHECK]
Press to perform device check for the parts mounted on the device table for the current production
program.
Caution: On machines equipped with a handy terminal, device check instructions are sent to the handy
terminal using the [CHECK] command.
Device check cannot be performed on the machine. The message “Checking Devices by HT” will
display on the handy terminal during device check. The [CHECK] key is disabled during device
check using the handy terminal. In any case this page can be exited using [RETURN].
Select the device check mode.
Revision History
