Board Loader PLC Output 1 LED No. No. Display Description A00 LY000 PCB REQ OUT Board request signal to preceding stage A01 LY001 PCB AVAIL OUT Board available signal to next stage A02 LY002 IN CONVEYOR In-conveyor motor…

Board Loader PLC Input 3

LED No. No. Display Description

A00 LX040 IN CRRY CL LF In-carrier left-front closed

A01 LX041 IN CRRY CL LR In-carrier left-rear closed

A02 LX042 IN CRRY CL RF In-carrier right-front closed

A03 LX043 IN CRRY CL RR In-carrier right-rear closed

A04 LX044 IN CRRY OP LF In-carrier left-front open

A05 LX045 IN CRRY OP LR In-carrier left-rear open

A06 LX046 IN CRRY OP RF In-carrier right-front open

A07 LX047 IN CRRY OP RR In-carrier right-rear open

A08 LX048 OUT CRRY CL LF Out-carrier left-front closed

A09 LX049 OUT CRRY CL LR Out-carrier left-rear closed

A0A LX04A OUT CRRY CL RF Out-carrier right-front closed

A0B LX04B OUT CRRY CL RR Out-carrier right-rear closed

A0C LX04C OUT CRRY OP LF Out-carrier left-front open

A0D LX04D OUT CRRY OP LR Out-carrier left-rear open

A0E LX04E OUT CRRY OP RF Out-carrier right-front open

A0F LX04F OUT CRRY OP RR Out-carrier right-rear open

Part 6 Chapter 2 Loader I/O

Edition 1.1 6-2-3 CP643E System Reference

Board Loader PLC Output 1

LED No. No. Display Description

A00 LY000 PCB REQ OUT Board request signal to preceding stage

A01 LY001 PCB AVAIL OUT Board available signal to next stage

A02 LY002 IN CONVEYOR In-conveyor motor on

A03 LY003 IN REDUCE In-conveyor motor decelerated

A04 LY004 IN STPR UP In-conveyor stopper on

A05 LY005 IN STPR DWN In-conveyor stopper off

A06 LY006 IN2 STPR UP Out-conveyor stopper on

A07 LY007 IN2 STPR DWN Out-conveyor stopper off

A08 LY008 OUT CONVEYOR Out-conveyor motor on

A09 LY009 (Reserved)

A0A LY00A IN CRRY CLOSE In-carrier closed

A0B LY00B IN CRRY OPEN In-carrier open

A0C LY00C IN CRRY FWD In-carrier advanced

A0D LY00D IN CRRY BWD In-carrier retracted

A0E LY00E IN LFTR UP In-lifter lifted

A0F LY00F IN LFTR DWN In-lifter lowered

B00 LY010 ID CONV ON MCID conveyor motor on

B01 LY011 ID DECEL ON MCID conveyor motor decelerated

B02 LY012 ID REVERSE ON MCID conveyor motor reversed

B03 LY013 ID W.MOTOR ON MCID width adjustment motor operated

B04 LY014 ID W.MOTOR REV MCID width adjustment motor reversed

B05 LY015 ID STPR1 ON MCID forward rotation stopper on

B06 LY016 ID STPR2 ON MCID reverse rotation stopper on

B07 LY017 (Reserved)

B08 LY018 IN2 STPR UP IN Conveyor Stopper Up.

B09 LY019 IN2 STPR DN ED IN Conveyor Stopper Down.

B0A LY01A OUT CRRY CLOSE Out-carrier closed

B0B LY01B OUT CRRY OPEN Out-carrier open

B0C LY01C OUT CRRY FWD Out-carrier advanced

B0D LY01D OUT CRRY BWD Out-carrier retracted

B0E LY01E OUT LFTR UP Out-lifter lifted

B0F LY01F OUT LFTR DWN Out-lifter lowered

Part 6 Chapter 2 Loader I/O

Edition 1.1 6-2-4 CP643E System Reference

3. OP Link

OP Link Input 1 MX250 Address 0xef0280

LED No. No. Display Description

A00 LX200 LOADER PLC OK Board loading sequencer functional

A01 LX201 LOADER ALARM1 Board loader alarm 1

A02 LX202 LOADER ALARM2 Board loader alarm 2

A03 LX203 IN LDR CMPLT In-loader operation completed

A04 LX204 CLEAROFF CMPLT Board unloading completed

A05 LX205 PCB WAIT Awaiting next board

A06 LX206 NEXT WAIT Waiting for next stage available

A07 LX207 IN LDR WORK In-loader operated

A08 LX208 OUT LFTR UP ED Out-lifter upper limit

A09 LX209 OUT LFTR DN ED Out-lifter lower limit

A0A LX20A ID PCB OUT MCID board unloading completed

A0B LX20B ID PCB CHK1 MCID forward rotation board detection

A0C LX20C ID PCB CHK2 MCID reverse rotation board detection

A0D LX20D W.CONV PERMIT Conveyor width change permission

A0E LX20E LOADER ALARM3 Board loader alarm 3

A0F LX20F OUT CRRY FD ED Out-carrier advance end

B00 LX210 OUT1/2 PCB GAP Out-conveyor 1/2 board clearance

B01 LX211 IN1 REDUCED POS In-conveyor 1 board deceleration position

B02 LX212 IN2 REDUCED POS In-conveyor 2 board deceleration position

B03 LX213 IDLE TIME SIG Idling time measurement

B04 LX214 (Reserved)

B05 LX215 (Reserved)

B06 LX216 (Reserved)

B07 LX217 DATA SET COMP Data set completed

B08 LX218 LD I/O DATA0 I/O data 0

B09 LX219 LD I/O DATA1 I/O data 1

B0A LX21A LD I/O DATA2 I/O data 2

B0B LX21B LD I/O DATA3 I/O data 3

B0C LX21C LD I/O DATA4 I/O data 4

B0D LX21D LD I/O DATA5 I/O data 5

B0E LX21E LD I/O DATA6 I/O data 6

B0F LX21F LD I/O DATA7 I/O data 7

Part 6 Chapter 3 OP Link

Edition 1.0 6-3-1 CP643E System Reference
