8. Cut the power, and then restart the machine.

Even though the power has been cut, the status data, Proper data and programs will

remain in the machine.

After this, continue with normal operation.

I/O Check Start

This subsection explains how to enter the I/O check mode.

Press the [F1] function key and hold it down while pressing the POWER ON button.

This will bring the machine directly into I/O Check Mode. For further information on

I/O check operation, refer to Part 3, “Commands”.

Caution: When I/O check start is used to start the machine, the 200V power does not come on.

When the RETURN command is used to leave the I/O Check mode, the 200V power is

restored and a zero-setting operation is enabled.

Part 2 Chapter 1 Basic Operation

Edition 1.1 2-1-18 CP643E System Reference

1.3 Starting Automatic Operation

1.3.1 Selecting a Production Program

There are two fields in the machine memory where the production programs are stored:

foreground and background. A program must be in the foreground to be used for

assembly. Up to nine spare programs can be stored in the background. You can select

the production program to be used in production by carrying out the following

procedure or transmit straight from the host to the machine foreground (refer to your

host documentation for details of this procedure).

Procedure

1. With the machine booted up and the desired program already transmitted to the

machine background, press [PROGRAM]. The [PROGRAM] screen displays, showing

a list of all the programs currently held at the machine.

2. Press [CHANGE]. The message "Program number?" displays in the second status

area.

3. Input the desired program number using numerical keypad. The selected program

replaces the former foreground program.

1.3.2 Modes of Running the Machine

The machine has settings which allow the user to set how the machine runs. These

settings are divided into Operation modes, Production modes and Pass mode.

Operation Modes

Automatic Operation: The machine operates continuously without stopping between

each sequence. Under the following conditions, the machine will stop and exit automatic

operation.

1) The CYCLE STOP button has been pressed.

2) The scheduled production quantity has been completed.

3) When the last sequence is finished during "S Stop", "D Stop" or "Clear Off" operation.

4) There are no parts, or an error has occurred in automatic recovery mode.

5) There are no parts, or an error has occurred in placing (error stop mode).

6) The nozzle statistical processing function is being used, and the number of nozzles

that have been skipped has reached the limit set in Proper Data.

7) Large parts are not being picked (only those parts specified as large parts in Part

Data).

8) An abnormal machine movement has occurred.

9) An emergency stop occurred.

10) Data calculations necessary for placing parts did not finish in time.

11) Vision processing did not finish in time.

Command Pass: [AUTO] - START

Step Operation: The machine operates one sequence at a time. After every sequence, the

message "Press START" appears. After the last sequence the board is removed from the

XY-table and the message "Press START" appears. When there is no board on the XY-

table, a board is loaded, and after one sequence, the message "Press START" appears. In

all other aspects the machine operates as if it were in automatic operation mode.

Command Pass: [STEP] - START

Part 2 Chapter 1 Basic Operation

Edition 1.1 2-1-19 CP643E System Reference

Production Modes

Product: This mode is used for producing boards. Parts are picked up, parts inspection

is performed and the parts are placed on the boards.

Simulate: This mode is used for such purposes as verifying placing coordinates. Parts

are not picked up. The XY-table and the device tables operate as they do during

production.

Idle: This mode is used for such purposes as machine adjustment, testing or machine

warm-up. Continuous operation is performed without changing the board or

performing vision processing. The placing heads descend at stations 1 and 11. The

carrier operation is not performed. When using this mode, the feeders should be

removed from the device tables.

Idle 2: This mode is also used for such purposes as machine adjustment, testing or

machine warm-up. In addition to the Idle operation, the carrier operation is performed.

When using this mode, the feeders should be removed from the device tables.

Command Pass: [AUTO] or [STEP] - [MODE] - Select [PRODUCT], [SIMULATE], [IDLE]

or [IDLE 2]

Pass: This mode is used when the machine is not used in current production. The

machine simply acts as a board conveyor, moving the board on to the next machine in

the line.

Pass Mode

The two ways of carrying out Pass mode are described below.

• Set Production_mode in the program to Pass.

• Select the command sequence [SET] – [STATUS] – [PASS].

If Pass mode was set in Production_mode in the program then the message “Pass” will

display in yellow at the machine. If Pass mode was set using the command keys at the

machine then the message "Pass" will display in blue (at the machine).

1.3.3 Setting the Device Table Mode

On the machine there are three device table modes: joint mode, device change mode and

changeover mode. An explanation of each mode follows.

Joint Mode

Tables 1 and 2 move synchronously as one large table capable of handling up to 140

devices.

This mode is used in programs with a large number of parts.

The device table from which parts are being picked is referred to as the "production

table" while the table from which parts are not being picked is called the "follow-up

table".

Table 1 Table 2

CP643S2009B

Machine display : "Joint"
