DATA NAME INPUT RANGE
$ 56: Terminal Type = [CRX1200] VT-100
# 57: Code Terminal Port (0~30) = 00
# 70: Device Check SW = No [Parts] Miss Error
# 71: Verifier Tool =[Non] Barcode Handy_term
# 72: Barcode Reader Type (0~9) = 0
# 73: Device Check Port (0~30) = 00
# 74: ESC Permission = Non [Permit]
# 75: MAN Permission = Non [Permit]
# 76: HT Comment Term. Code ASCII CODE = %
# 77: HT Verify Term. Code ASCII CODE = /
# 78: D Change Trigger = [Error] Parts Miss PD
# 80: HT Check Character = [No] Yes
✩* 100: FQ Origin Position (-30000~30000) [pulse] = 00000
✩* 101: FRQ Origin Position (-30000~30000) [pulse] = 00000
✩* 102: NC Origin Position (-30000~30000) [pulse] = 00000
✩* 103: Pickup Position T1 (-500000~0) [pulse] = 000000
✩* 104: Pickup Position T2 (0~500000) [pulse] = 000000
✩* 105: Origin Position Z (-65000~65000) [pulse] = 00000
✩* 106: Placing Position X (-100000~0) [pulse] = 000000
✩* 107: Placing Position Y (0~100000) [pulse] = 000000
✩* 108: Loading Position X IN (-100000~0) [pulse] = 000000
✩* 109: Loading Position X OUT (-100000~0) [pulse] = 000000
✩* 110: Loading Position Y IN (-100000~0) [pulse] = 00000
✩* 111: Loading Position Y OUT (-100000~0) [pulse] = 00000
✩* 112: Middle Loading Position (-65000~65000) [pulse] = 00000
✩* 113: Mark Read Position X (-100000~100000) [pulse] = 000000
✩* 114: Mark Read Position Y (0~100000) [pulse] = 000000
✩* 115: PCB Check Position X (-100000~100000) [pulse] = -27200
✩* 116: PCB Check Position Y (0~100000) [pulse] = 37900
✩* 117: D1 Origin Position (-10000~10000) [pulse] = 00000
✩* 118: D2 Origin Position (-10000~10000) [pulse] = 00000
✩* 119: Max Limit Position X (0~100000) [pulse] = 000000
✩* 120: Max Limit Position Y (0~100000) [pulse] = 000000
✩* 121: Max Limit Position D1 (0~100000) [pulse] = 000000
✩* 122: Max Limit Position D2 (-10000~500000) [pulse] = 000000
✩* 123: Max Limit Position Z (-65000~65000) [pulse] = 00000
✩* 124: Min Limit Position X (-100000~0) [pulse] = 000000
✩* 125: Min Limit Position Y (-100000~0) [pulse] = 000000
✩* 126: Min Limit Position D1 (-500000~10000) [pulse] = 000000
✩* 127: Min Limit Position D2 (-50000~50000) [pulse] = 00000
✩* 128: Min Limit Position Z (-65000~65000) [pulse] = 00000
✩* 129: Loading Position Z OUT (-65000~65000) [pulse] = 00000
✩* 130: Loading Position Z IN (-65000~65000) [pulse] = 00000
$ 131: Spare data (-1000~1000) = 00000
$ 132: Spare data (-1000~1000) = 00000
$ 133: Spare data (-1000~1000) = 00000
$ 134: Spare data (-1000~1000) = 00000
Part 4 Chapter 1 Proper Data Listing
Edition 1.0 4-1-2 CP643E System Reference
DATA NAME INPUT RANGE
$ 135: Spare data (-1000~1000) = 00000
$ 136: Spare data (-1000~1000) = 00000
# 137: PCB DISTANCE Check SW = No [Yes]
# 138: Skip Number (0~16) = 00
# 139: Skip Nozzle 1 (0~12) = 00
# 140: Skip Nozzle 2 (0~12) = 00
# 141: Skip Nozzle 3 (0~12) = 00
# 142: Skip Nozzle 4 (0~12) = 00
# 143: Skip Nozzle 5 (0~12) = 00
# 144: Skip Nozzle 6 (0~12) = 00
# 145: Nozzle Check SW = [Yes] No
* 146: Narrow View Camera = Non [Use]
* 147: Front Light (0~4) = 0
# 148: Cam Speed (0~100.0) [%] = 100.0
# 149: M/C PCB TYPE (0~1) = [4000] 5000
# 150: D ESC sw = [No] Yes
✩* 151: Place Offset Y 100 (-1000~1000) [1/1000 mm] = 00000
✩* 152: Place Offset Y 90 (-1000~1000) [1/1000 mm] = 00000
✩* 153: Place Offset Y 80 (-1000~1000) [1/1000 mm] = 00000
✩* 154: Place Offset Y 70 (-1000~1000) [1/1000 mm] = 00000
✩* 155: Place Offset Y 60 (-1000~1000) [1/1000 mm] = 00000
✩* 156: Reach Pulse C (0~65535) [pulse] = 00000
✩* 157: Reach Pulse FRQ (0~65535) [pulse] = 00000
✩* 158: Reach Pulse FQ (0~65535) [pulse] = 00000
✩* 159: Reach Pulse X (0~65535) [pulse] = 00000
✩* 160: Reach Pulse Y (0~65535) [pulse] = 00000
✩* 161: Reach Pulse Z (0~65535) [pulse] = 00000
✩* 162: Reach Pulse D1 (0~65535) [pulse] = 00000
✩* 163: Reach Pulse D2 (0~65535) [pulse] = 00000
✩* 164: Reach Pulse NC (0~65535) [pulse] = 00000
$ 165: Spare data (-1000~1000) = 00000
✩* 166: A1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 167: B1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 168: C1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 169: D1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 170: E1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 171: F1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 172: G1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 173: H1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 174: I1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 175: J1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 176: K1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 177: L1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 178: M1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 179: N1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 180: O1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 181: P1 Place Offset X (-327.68~327.67) [mm] = 000.00
Part 4 Chapter 1 Proper Data Listing
Edition 1.0 4-1-3 CP643E System Reference
DATA NAME INPUT RANGE
✩* 182: Q1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 183: R1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 184: S1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 185: T1 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 186: A2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 187: B2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 188: C2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 189: D2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 190: E2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 191: F2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 192: G2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 193: H2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 194: I2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 195: J2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 196: K2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 197: L2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 198: M2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 199: N2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 200: O2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 201: P2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 202: Q2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 203: R2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 204: S2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 205: T2 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 206: A3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 207: B3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 208: C3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 209: D3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 210: E3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 211: F3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 212: G3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 213: H3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 214: I3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 215: J3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 216: K3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 217: L3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 218: M3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 219: N3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 220: O3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 221: P3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 222: Q3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 223: R3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 224: S3 Place Offset X (-327.68~327.67) [mm] = 000.00
✩* 225: T3 Place Offset X (-327.68~327.67) [mm] = 000.00
Part 4 Chapter 1 Proper Data Listing
Edition 1.0 4-1-4 CP643E System Reference
