Input 3 MX250 Address 0xef0240
LED No. No. Display Description
A00 X040 SERVO BOX1 Servo box 1 functional
A01 X041 SERVO BOX2 Servo box 2 functional
A02 X042 TAPE END CHK Tape end detection
A03 X043 L PICKUP CHK Station 2 large parts pickup
A04 X044 PQ ROT. 270DEG Pretheta rotation cylinder advance
A05 X045 PQ ROT. 90DEG Pretheta rotation cylinder retract
A06 X046 SET CANCEL 1 Right device table set cancel
A07 X047 SET CANCEL 2 Left device table set cancel
A08 X048 MIDDLE DEVICE 50 / 50 feeder arrangement specified
A09 X049 HEAD A CHK Head A detection
A0A X04A NOZ CHK ST17 1 Station 17 nozzle type check 1
A0B X04B NOZ CHK ST17 2 Station 17 nozzle type check 2
A0C X04C NOZ CHK ST17 3 Station 17 nozzle type check 3
A0D X04D NOZ CHK ST19 1 Station 19 nozzle type check 1
A0E X04E NOZ CHK ST19 2 Station 19 nozzle type check 2
A0F X04F NOZ CHK ST19 3 Station 19 nozzle type check 3
B00 X050 PRQ ROT. 270DEG PRQ rotation cylinder advance
B01 X051 PRQ ROT. 90DEG PRQ rotation cylinder retract
B02 X052 NOZ ORG POS ST12 Station 12 nozzle clutch origin position
B03 X053 NOZ CLUT. ST 12 Station 12 nozzle clutch engaged
B04 X054 DUMP PARTS Reject parts box full
B05 X055 OIL ALARM Oil circulation alarm
B06 X056 NOZ ORG POS ST15 Station 15 nozzle clutch origin position
B07 X057 CYCLE MODE Cycle stop mode (V1.35)
B08 X058 SET COMPLETE1 Parts set complete 1
B09 X059 SET COMPLETE2 Parts set complete 2
B0A X05A SHUTTER1 UPCHK Shutter 1 raised
B0B X05B SHUTTER1 DNCHK Shutter 1 lowered
B0C X05C SHUTTER2 UPCHK Shutter 2 raised
B0D X05D SHUTTER2 DNCHK Shutter 2 lowered
B0E X05E TRANSFER IN In-conveyor board transfer
B0F X05F TRANSFER OUT Out-conveyor board transfer
Part 6 Chapter 1 Standard I/O
Edition 1.0 6-1-3 CP643E System Reference
Input 4 MX250 Address 0xef0260
LED No. No. Display Description
A00 X060 M-LFT CLMP F Main lifter board clamp (front side)
A01 X061 M-LFT CLMP R Main lifter board clamp (rear side)
A02 X062 M-LFT UNCLMP F Main lifter board unclamp (front side)
A03 X064 M-LFT UNCLMP R Main lifter board unclamp (rear side)
A04 X065 M-LFTR UP1 Main lifter upper limit 1
A05 X066 M-LFTR UP2 Main lifter upper limit 2
A06 X067 M-LFTR MO-TRVL Main lifter middle overtravel
A07 X067 M-LFTR DWN END Main lifter lower limit
A08 X068 XY IN L POS XY-table loading position (inside)
A09 X069 XY OUT L POS XY-table loading position (outside)
A0A X06A ST1 UP POS ST 1 cylinder upper limit
A0B X06B ST 11 UP POS ST 11 cylinder upper limit
A0C X06C (Reserved)
A0D X06D (Reserved)
A0E X06E (Reserved)
A0F X06F (Reserved)
Part 6 Chapter 1 Standard I/O
Edition 1.0 6-1-4 CP643E System Reference
Output1 MX250 Address 0xef0300
LED No. No. Display Description
A00 Y000 START LAMP ON Start button lamp on
A01 Y001 RESET LAMP ON Reset button lamp on
A02 Y002 BUZZER ON Buzzer on
A03 Y003 TM CNTR ON New time counter on
A04 Y004 SERVO HOLD Maintaining servo power
A05 Y005 TIME COUNT ON Time counter on
A06 Y006 AUTO OPERATION In automatic operation mode
A07 Y007 (Reserved)
A08 Y008 TABLE UP
A09 Y009 TABLE DOWN
A0A Y00A CONV WIDE ON Widening conveyor width
A0B Y00B CONV NARROW Narrowing conveyor width
A0C Y00C D1 SERVO ON D1 axis servo power on
A0D Y00D D2 SERVO ON D2 axis servo power on
A0E Y00E SERVO ON Servos on other axes power on
A0F Y00F (Reserved)
B00 Y010 (Reserved)
B01 Y011 (Reserved)
B02 Y012 (Reserved)
B03 Y013 (Reserved)
B04 Y014 SHUTTER1 UP Shutter 1 raised
B05 Y015 SHUTTER1 DOWN Shutter 1 lowered
B06 Y016 SHUTTER2 UP Shutter 2 raised
B07 Y017 SHUTTER2 DOWN Shutter 2 lowered
B08 Y018 (Reserved)
B09 Y019 (Reserved)
B0A Y01A (Reserved)
B0B Y01B (Reserved)
B0C Y01C (Reserved)
B0D Y01D FOLLOW PERMIT Follow-up permission output to next stage
B0E Y01E BC LAMP1 ON Bar code reader lamp 1 on
B0F Y01F BC LAMP2 ON Bar code reader lamp 2 on
Part 6 Chapter 1 Standard I/O
Edition 1.0 6-1-5 CP643E System Reference
