TABLE 1 513-3-0
Command Pass : [SET] - [STATUS] - [TABLE MODE] - [TABLE 1]
When in the device change mode or changeover mode this command sets the original table as table
1.
Revision History
LINE 514-0-0
Command Pass : [SET] - [STATUS] - [LINE]
Press to select the communication mode with the host computer.
Revision History
MCS / GEM 514-1-0
Command Pass : [SET] - [STATUS] - [LINE MODE] - [MCS / GEM]
MCS: Press to toggle the communication mode with the host computer between the following
two settings:
Local: Only Status data, Proper data and programs can be sent from the host
computer.
Off Line: The CP-643E can send production data to the host computer.
Note : The communication mode setting is saved when the power supply is turned off. The
communication mode can also be changed by changing the status data.
GEM: This command only displays when the SECS/GEM communication protocol is used.
Refer to the CP-6 SECS/GEM Instruction Manual for details.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-40 CP643E System Reference
LMS 514-2-0
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS]
Press to access LMS related commands.
The user must input an ID code to enter this mode.
Revision History
CELL STATUS 514-2-1
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [CELL STATUS]
Press to change cell status.
Caution: When the cell status is changed it is also necessary to change the LMS data. Once this is done the
LMS must be shut down and rebooted. Furthermore, if this key is pressed it is necessary to shut
down the power to the machine and reboot in order to initialize the machine too.
Revision History
INITIALIZE 514-2-2
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [INITIALIZE]
Press to clear the contents of changeover memory. If for some reason changeover is interrupted
before completion, this key can be pressed to return to the original status.
Caution: When in HELPS compatible operation, changeover status is stored in memory when the power is cut,
so care should be taken not to press this key when it is not necessary. Furthermore, if this key is
pressed it is necessary to shut down the machine and reboot in order to initialize the machine.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-41 CP643E System Reference
CODE READ 514-2-3
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [CODE READ]
Press to start a bar code reader test when the ID conveyor is using the bar code reader.
Note: For further details refer to the ‘HELPS Operation Manual’.
Revision History
READER 1 514-2-3-1
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [CODE READ] - [READER 1]
Press to perform a test reading of the bar code on the upper surface of the board.
Revision History
READER 2 514-2-3-2
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [CODE READ] - [READER 2]
Press to perform a test reading of the bar code on the lower surface of the board.
Revision History
ADJ. TEST 514-2-4
Command Pass : [SET] - [STATUS] - [LINE MODE] - [LMS] - [ADJ. TEST]
This command provides entry to the command page for measuring the Proper data necessary for
width adjustment when conveyor width adjustment is carried out automatically.
Note: Refer to "HELPS Operation Manual" for further details.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-42 CP643E System Reference
