Servo Input 2 (X, Y, Fθ axes)

No. Display Description

SX010 NO2 EMERGENCY No. 2 servo board emergency stop input

SX011 Currently not in use

SX012 Currently not in use

SX013 Currently not in use

SX014 X AXIS +OT X axis overtravel (+)

SX015 X AXIS -OT X axis overtravel (-)

SX016 X AXIS ZERO X axis zero setting sensor

SX017 X AXIS READY X axis interlock

SX018 Y AXIS +OT Y axis overtravel (+)

SX019 Y AXIS -OT Y axis overtravel (-)

SX01A Y AXIS ZERO Y axis zero setting sensor

SX01B Y AXIS READY Y axis interlock

SX01C Currently not in use

SX01D Currently not in use

SX01E FQ AXIS ZERO FQ axis zero setting sensor

SX01F Currently not in use

Part 6 Chapter 4 Servo Board

Edition 1.0 6-4-2 CP643E System Reference

Servo Input 3 (D1, D2, NC axes)

No. Display Description

SX020 NO3 EMERGENCY No. 3 servo board emergency stop input

SX021 Currently not in use

SX022 Currently not in use

SX023 Currently not in use

SX024 D1 AXIS +OT D1 axis overtravel (+)

SX025 D1 AXIS -OT D1 axis overtravel (-)

SX026 D1 AXIS ZERO D1 axis zero setting sensor

SX027 D1 AXIS READY D1 axis interlock

SX028 D2 AXIS +OT D2 axis overtravel (+)

SX029 D2 AXIS -OT D2 axis overtravel (-)

SX02A D2 AXIS ZERO D2 axis zero setting sensor

SX02B D2 AXIS READY D2 axis interlock

SX02C Currently not in use

SX02D Currently not in use

SX02E NC AXIS ZERO NC axis zero setting sensor

SX02F Currently not in use

Part 6 Chapter 4 Servo Board

Edition 1.0 6-4-3 CP643E System Reference

Notes:

Part 6 Chapter 4 Servo Board

Edition 1.0 6-4-4 CP643E System Reference
