523 CENTER NOZZLE SKIP NZL TOL. WIDE NARROW CALB SPC NZL RESULTS RETURN 523/1 PAGE + NOZZLE – NOZZLE RETURN +PAGE -PAGE SIZE RETURN 523/11 523/15 WIDE NARROW RETURN 523/2 SIZE ▲ ▼ SKIP/CLEAR RETURN 524 HT RESET BC TEST R…
BUFFER IMG
TRACE
ADJUST
VISION TEST
RETURN
522
REINSPECT
TEMP. TRACE
SEL BUF IMG
DISPLAY
RETURN
522/1
GET ACQ
GAIN/OFFSET
to 522/33
RETURN
522/3
▲
▼
ON/OFF
CLEAR
RETURN
522/2
ZOOM IN
ZOOM OUT
SCROLL
RETURN
522/14
522/311
CHANGE
DSP REAL-IMG
RETURN
GET ACQ
DISPLAY
RETURN
522/31
F MARK
B MARK
RETURN
522/4
SET DATA
TEMP. TRACE
DSP REAL-IMG
VP. EXE.
OPERATE IMG
RETURN
522/42
SET DATA
LEVEL SET
SET SIZE
DSP REAL-IMG
VP. EXE.
RETURN
522/43
FORM DSPLY
TEMP. TRACE
DISPLAY
REINSPECT
DSP REAL-IMG
RETURN
522/425
522/312
ZOOM IN
ZOOM OUT
SCROLL
RETURN
522/144
<<<
>>>
▲
▼
STEP
RETURN
CP643S3004
▲
▼
SELECT
VISION TEST
RETURN
522/33
▲
■
▼
CLEAR
SELECT
RETURN
522/333
F MARK
B MARK
RETURN
522/334
to 522/42
to 522/43
522/3113
▲
▼
RETURN
Part 3 Chapter 1 Command Hierarchy
Edition 1.1 3-1-4 CP643E System Reference
523
CENTER
NOZZLE SKIP
NZL TOL.
WIDE
NARROW
CALB SPC NZL
RESULTS
RETURN
523/1
PAGE
+ NOZZLE
– NOZZLE
RETURN
+PAGE
-PAGE
SIZE
RETURN
523/11
523/15
WIDE
NARROW
RETURN
523/2
SIZE
▲
▼
SKIP/CLEAR
RETURN
524
HT RESET
BC TEST
RETURN
524/2
HT RESET
CODE READ
RETURN
TOLERANCE
B_lite Stndrd
RETURN
525
PLT CHK STOP
MEMORY
RETURN
GAIN/OFFSET
CAM ORG POS
SEQ. No
RETURN
525/1 525/11
▲
■
▼
CLEAR
SELECT
RETURN
WIDE
NARROW
RETURN
NOZZLE DATA
BACKLIGHT DATA
RETURN
523/151
▲
▼
RETURN
523/111
523/113
523/1512
523/1511
CP643S3005
▼
Part 3 Chapter 1 Command Hierarchy
Edition 1.1 3-1-5 CP643E System Reference
CAMERA
X/Y
D1/D2
FQ/ FRQ/ NC
Z
RETURN
530
XC/YC
MARK
WIDE VIEW
NARROW VIEW (*1)
BIRGHT
RETURN
531
X0/Y0
PCB LD/UNLD
XPCB/YPCB
Xmax/Ymax
Xmin/Ymin
RETURN
532
Pickup Pos.
ORIGIN
Max Limit
Min Limit
RETURN
533
SET
Z0
SPEED
RETURN
ISTART SW
531/1
RETURN
ISTART SW
531/2
POSITION 1
POSITION 2
RETURN
ISTART SW
531/3,4
RETURN
ISTART SW
531/13
MARK CAMERA
WIDE VIEW
NARROW VIEW
RETURN
531/5
SET
RETURN
532/1
▲
■
▼
SELECT
RETURN
531/51
PICKUP T1
PICKUP T2
RETURN
533/1
D1 ORIGN
D2 ORIGN
RETURN
533/2
D1 Max
D2 Max
RETURN
533/3
D1 Min
D2 Min
RETURN
533/4
POSITION 2
CHECK
RETURN
SET
RETURN
533/11
FQ ORIGIN
FRQ ORIGIN
NC ORIGIN
RETURN
534
SET
RETURN
534/1,2,3
CP643S3006
*: For narrow view camera
UNLOAD POS.
LOAD POS.
RETURN
532/2
SET
RETURN
532/21, 22
ZL
Z0
Z max
Z min
M_load_pos
RETURN
535
ZL_OUT
ZL_IN
RETURN
535/1
SET
RETURN
535/11, 12
to 532-2
Part 3 Chapter 1 Command Hierarchy
Edition 1.1 3-1-6 CP643E System Reference
