Min Limit 533-4-0 Command Pass: [SET] - [PROPER] - [D1/D2] - [Min Limit] Press to set the D axis negative stroke in Proper data. Revision History V1.10 and later D1 Min 533-4-1 Command Pass: [SET] - [PROPER] - [D1/D2] - …
Max Limit 533-3-0
Command Pass: [SET] - [PROPER] - [D1/D2] - [Max Limit]
Press to set the D positive stroke in Proper data.
Revision History
V1.10 and later
D1 Max 533-3-1
Command Pass: [SET] - [PROPER] - [D1/D2] - [Max Limit] - [D1 Max]
Press to set the D1 max measurement results in Proper data.
Revision History
V1.10 and later
D2 Max 533-3-2
Command Pass: [SET] - [PROPER] - [D1/D2] - [Max Limit] - [D2 Max]
Press to set the D2 max measurement results in Proper data.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-96 CP643E System Reference
Min Limit 533-4-0
Command Pass: [SET] - [PROPER] - [D1/D2] - [Min Limit]
Press to set the D axis negative stroke in Proper data.
Revision History
V1.10 and later
D1 Min 533-4-1
Command Pass: [SET] - [PROPER] - [D1/D2] - [Max Limit] - [D1 Min]
Press to set the D1 min measurement results in Proper data.
Revision History
V1.10 and later
D2 Min 533-4-2
Command Pass: [SET] - [PROPER] - [D1/D2] - [Max Limit] - [D2 Min]
Press to set the D2 min measurement results in Proper data.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-97 CP643E System Reference
FQ/FRQ/NC 534-0-0
Command Pass: [SET] - [PROPER] - [FQ/FRQ/NC]
Press to set the FQ-, FRQ- and NC-axes Proper data values.
Revision History
FQ ORIGIN 534-1-0
Command Pass: [SET] - [PROPER] - [FQ/FRQ/NC] - [FQ ORIGIN]
Press to measure the FQ ORIGIN results for Proper data.
Revision History
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-98 CP643E System Reference
