SET DATA 522-4-2-1
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [SET DATA]
This sets the fiducial mark used for carrying out test processing. Specify the sequence number.
Processing after numeric keypad input
If the numeric keypad is used to input a fiducial mark sequence number that exists in the
production program stored in the foreground on the machine, each type of data (camera, scan area,
fiducial mark ID) must be set so that the fiducial mark of the specified sequence can be vision
processed.
After input is completed, each set value displays under the relevant item on the screen (“Pattern”,
“B/W”, Size_a”, “Size_b”, “Size_c”, and “Scan”) and the fiducial mark applicable for test
processing is determined.
Revision History
V1.10 and later
TEMP. TRACE 522-4-2-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [TEMP. TRACE]
Each type of button can be set so that a vision processing trace and the results of vision processing
are graphically displayed on the monitor.
Revision History
V1.10 and later
DSP REAL-IMG 522-4-2-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [DSP REAL-IMG]
This command can be used to display the actual mark camera image on the monitor. If this
command is selected the fiducial camera light comes on and the actual image is acquired.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-65 CP643E System Reference
VP. EXE. 522-4-2-4
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [VP. EXE.]
Vision processing can be executed after the image of the mark for the specified sequence has been
acquired.
Note:
1. If F1 [SET DATA] has not been executed this command cannot be executed.
2. If a board is not set on the XY table a vision processing error will result.
Processing after START is pressed
After the interference check (nozzles, conveyor width notch, and reference pin) the XY table moves
to the point on the board above the mark specified in the sequence. Once movement is completed
the mark camera light comes on and the mark image is acquired. Vision processing is carried out
after the image is acquired.
Revision History
V1.10 and later
OPERATE IMG 522-4-2-5
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
The image acquired using [OPERATE IMG] can be utilized for finding the cause of an error when a
vision processing error occurs.
Note: If F1 [SET DATA] has not been executed this command cannot be executed.
Revision History
V1.10 and later
FORM DSPLY 522-4-2-5-1
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [FORM DSPLY]
This command is used to verify whether the fiducial mark data is correct.
This command can only be executed when using V2.80 or later version of the vision processing
card.
Revision History
V1.10 and later
Part 3 Chapter 3 Command Descriptions
Edition 1.0 3-3-66 CP643E System Reference
TEMP. TRACE 522-4-2-5-2
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [TEMP. TRACE]
Each type of button can be set for graphically displaying a vision processing trace on the monitor
and for displaying the processing results.
Revision History
V1.10 and later
DISPLAY 522-4-2-5-3
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [DISPLAY]
This command is used to display the acquired image on the monitor.
Revision History
V1.10 and later
REINSPECT 522-4-2-5-4
Command Pass: [SET] - [MANUAL] - [VISION] - [VISION TEST] - [F MARK] - [OPERATE IMG]
- [REINSPECT]
Vision processing is performed again using the acquired image in order to check the cause and
vision processing trace of an error that has occurred.
Revision History
V1.10 and later
