(2) Display When Not In Automatic Operation Area A: Information about all stations from one to eleven is displayed. Caution: The number of the next device from which parts were picked displays in the case that the target…
Area C: Special operations procedures display here.
Area D: Information about optional functions display here.
• In the case of Handy Terminal compatible operation
When the next program has been specified, the name of this program will display
here.
• When operating in the HELPS mode
The name of the announcement or reservation program will display here.
Display
Ending one board production
Ending two board production
Unloading
Checking Device by HT
Calculating Placing Data
Vision processing
Meaning
After finishing the board currently being processed
the machine will stop.
Machine is being stopped following two board
production operation.
Machine is being stopped after all boards in the
machine (on the in-conveyor, in-carrier, main
conveyor, out-carrier, and out-conveyor) have been
completed and unloaded.
Device check is currently being carried out using a
Handy Terminal.
Calculation of data necessary for placing parts is
currently being carried out.
Waiting for vision processing to be completed.
CP643S1026
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-21 CP643E System Reference
(2) Display When Not In Automatic Operation
Area A: Information about all stations from one to eleven is displayed.
Caution: The number of the next device from which parts were picked displays in the case that the
target device was part of a next device loop. In Changeover or Device Change mode,
when Device Table 2 (71-140: 51 ~ 100 for the CP-643ME) is the original table, the
device positions will be displayed as 71 ~ 140 (CP-643ME: 51 ~ 100).
Area B: The operation modes are displayed here in the same way they are during
automatic operation.
Area C: Information about special operations is displayed here.
Area D: This display is the same as in the automatic operation display.
Display
Sequence End Stop
Meaning
Machine stopping operation after finishing the
currently processed board is completed.
Sequences End Stop
“Machine stop” processing which follows
two board production is completed.
CP643S1029
Clear Off Complete
“Machine stop” processing which follows the
completion and unloading of all boards in the
machine (on the in-conveyor, in-carrier, main
conveyor, out-carrier, and out-conveyor) has
been completed.
Display
ST1.N
ST2.N
ST3.N
ST6.N
ST7.N
ST8.N
ST10.N
ST11.N
Mening
For station 1~6, sequence and device numbers for each station
are displayed. "Er***" , means that vision processing has
not yet being completed.
For station 7~11, sequence and device numbers and result of
vision processing for each station are displayed.
As the result of vision processing, "0" indicates that production
has been completed under the normal condition.
Error code displays if the vision processing is not completed
normally.
CP643S1028
11D 35 Er ****
10D 35 Er ****
9D 35 Er ****
6D 35 Er ****
5D 35 Er 0
4D 35 Er 0
2D 35 Er 0
1D 35 Er 0
ST 1. N
ST 2. N
ST 3. N
ST 6. N
ST 7. N
ST 8. N
ST10. N
ST11. N
Sequence End Stop
NEXT PROD: TEST PROGRAM 1
CP643S1027
10
9
8
5
4
3
1
Skip
STATUS
P Mode
Recovery
T Mode
: Product
: 3 times
: Joint
AB
C
D
D 35 Er ****
D 35 Er ****
D 35 Er ****
D 35 Er ****
D 35 Er 0
D 35 Er 0
D 35 Er 0
D 35 Er
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-22 CP643E System Reference
1.3.3 Second Display Area
The second display area displays machine error status and
messages to the operator.
Area A: Current Machine Status Display Area
This area displays the current status of the machine.
Display
Emergency Stop
Meaning
Under emergency conditions, this will be displayed.
When this happens, refer to area B for the reasons.
The machine has stopped with errors and is waiting for
the operator to press the RESET button.
Before the start of operation, the operator must push
the START button.
This item indicated that zero-setting has not yet been
performed after the machine's power has been turned ON.
This item indicates that nozzle origin search is being
carried out.
This item indicates that zero-setting is being carried out.
The machine is operating and can receive commands at
this point.
This displays if the cam axis is not at 0 degrees.
The machine is now measuring Proper data.
Operation is being conducted with the Handy Terminal.
In HELPS mode, changeover occurs automatically and
this message displays.
The machine is now placing parts.
A board is being loaded onto or unloaded from the
XY-table.
The machine has stopped and is waiting for the next
board to be loaded.
The next machine has not yet requested a new board,
so the machine is waiting.
The machine cannot be restored until the power has been
shut off and restarted.
Waiting for reset SW
CP643S1032
Press START
Machine Not Zero Set
Searching for origin...
Zero Set
Ready
Return Cam to Zero
Measuring Proper...
Operating HT...
Changing Over...
Producing...
Operating Loader
Waiting for PCB
Waiting for NEXT
Shut off power
Emergency Stop
Waiting for Reset SW
Emergency Stop Pressed
D100 Resupply
CP643S1031
A
B
C
D
Skip
1ABCD
2CD
3DEF
Nozzle
4ABCD
5MN
6AT
Tape End
105 124
012
075
E
CP643S1030
Part 1 Chapter 1 Machine Overview
Edition 1.1 1-1-23 CP643E System Reference
