3.5.2 BGA components (BGA setting)
BGA components are registered with the parameters shown below when
the AlignmentType parameter is set to “BGA”. With this setting, the BGA
arrangement and nicked leads can bet checked.
BGA component parameters (when AlignmentModule is set to “BGA”)
27516-D8-00
6.SHAPE INFO.
Body Size X
Body Size Y
Body Size Z
Dot number N
Dot number E
BGA diameter
BGA pitch N
BGA pitch E
Dot amount
Binary Level
:
:
:
:
:
:
:
:
:
:
23.00
23.00
1.80
13
13
0.75
1.50
1.50
169
0
5.VISION INFO.
Alignment Group
Alignment Type
AlignmentModule
Light Selection
Lighting Level
Comp. Threshold
Comp. Tolerance
Search Area mm
Datum Angle
Comp. Intensity
MultiCam. Marker
:
:
:
:
:
:
:
:
:
:
:
Ball
BGA
Fore
Main + Coax
4/8
Non effective
Normal
NotUse
30
1.50
0
1.BASIC INFO.
Database No.
Comp. Package
Feeder Type
Required Nozzle
Feeder Set No.
Pos. Definition
Feeder Pos_X mm
:
:
:
:
:
:
:
Tape
32mmEmboss
ForQFP30mm 74
Teaching
950
7
-16.00
2.OPTION INFO.
FixCmpRef.
AIt.Cmp
Use feeder opt.
Comp. Group No.
Correct Pickpos
:
:
:
:
:
Yes
Not Use
0
0
0
3.PICK AND MOUNT INFO.
Pick Angle deg
Pick Timer
Mount Timer
Mnt Height
Pick Sequence
Mount Action
Mount Speed
PickupSpeed
XY Speed
Vacuum Check
Pick Vacuum
Mount Vacuum
Conv. Y Speed
:
:
:
:
:
:
:
:
:
:
:
:
:
4.DUMP INFO.
Dump Way
Retry Times
:
:
Dump POS
2
s
s
mm
%
%
%
%
%
0
0.30
0.20
Normal
QFP
30
100
100
SPECIAL CHK
FAST
0.0
10
10
mm
mm
mm
mm
mm
mm
1
2
3
4
5
6
41
42
43
44
45
46
47
48
49
50
51
11
12
13
14
15
31
32
61
62
63
64
64
65
66
67
21
22
23
24
25
26
27
28
n
NOTE
When setting the parameters shown in the sub-windows above, use the number keys to set
the parameters aligned on the right, while using the [INS], [DEL] or [Space] key to set
the parameters aligned on the left. However, there are some parameters which should be
set or optimized with the Adjust Assistant commands described later in “3.7” in this
chapter.
The displayed parameters differ slightly depending on the <3/1/A1 OPTION CONFIG>
settings.
5
-47
EPD8008100
Operation
Chapter 5
5
Creating the PCB data
1. BASIC INFO. parameters
1. Comp. Package
Refer to the description in “3.3.1 Standard chip components”.
2. Feeder Type
Refer to the description in “3.3.1 Standard chip components”.
3. Required Nozzle
Select the optimum nozzle that matches the component size from among
the nozzle types for QFP components. (See “Nozzle table” listed in
Supplement in this manual.)
4. Feeder Set No.
Refer to the description in “3.3.1 Standard chip components”.
5. Pos. Definition
Refer to the description in “3.3.1 Standard chip components”.
6. Feeder Pos_X
Refer to the description in “3.3.1 Standard chip components”.
2. OPTION INFO. parameters
For descriptions of the following OPTION INFO. parameters, refer to
“3.3.1 Standard chip components” in this chapter.
11. FixCmpRef.
12. Alt. Comp.
13. Use feeder opt.
14. Comp. Group No.
15. Correct Pickpos.
3. PICK & MOUNT INFO. parameters
21. Pick Angle deg
Use the same setting as for QFP components.
22. Pick Timer, Mount Timer
Refer to the description in “3.4.2 SOP component”.
23. Pick Height, Mount Height
Refer to the description in “3.3.1 Standard chip components”.
24. Pick Sequence
Refer to the description in “3.3.1 Standard chip components”.
25. Mount Action
Set this parameter to “QFP” when mounting accuracy is more important
than operation speed. (Refer to the description in “3.3.4 QFP components”
for detail.)
26. Vacuum Check
Set this parameter to “SPECIAL CHK” in most cases. (Refer to the
description in “3.3.4 QFP components” for detail. )
5
-48
EPD8008100
Operation
Chapter 5
5
Creating the PCB data
27. Pick Vacuum, Mount Vacuum
These are reference vacuum pressures used for checking the pickup and
mount vacuum levels. Use the default settings and adjust them as needed
in the Adjust Assistant mode. (See “3.7” in this chapter.)
28. Conv. Y Speed
Refer to the description in “3.3.1 Standard chip components”.
4. DUMP INFO. parameters
31. Dump Way
Set to “Station” when a dump station (option) is used and to “Dump POS.”
when not used. Refer to the Discard point parameter explained in the
mounter service manual.
32. Retry Times
Refer to the description in “3.3.1 Standard chip components”.
5. VISION INFO. parameters
41. Alignment Group
Set to “Ball”.
42. Alignment Type
Set to “BGA”.
43. AlignmentModule
This parameter specifies the lighting method for recognizing a component.
Use the default setting (Fore).
For descriptions of the following VISION INFO. parameters, refer to
“3.3.1 Standard chip components”.
44. Light Selection
Set this parameter to “Main + Coax” to edit the arrangement of the BGA
leads. If you want to check nicks on the BGA leads, set to “Only Side“.
45. Lighting Level
46. Comp. Threshold
This parameter is skipped for BGA components.
47. Comp. Tolerance
48. Search Area
49. Datum Angle
50. Comp. Intensity
51. MultiCam. Marker
