6 -12 EPD8013110 Operation Chapter 6 6 Using various functions 2.2.2 Reconver ting to the block repeat data When editing or correcting one-block PCB data which was con verted from block repeat data, it will prove con ven…

100%1 / 307
6
-11
EPD8013110
Operation
Chapter 6
6
Using various functions
5 Set the “FEEDER SET CONDITION” parameter.
Set this parameter to “NO” when performing only the block conversion.
Refer to “9.2 Setting optimization conditions” in Chapter 5 for more
details.
6 Execute the block conversion.
Press the [ESC] key to return to the <2/2/A/SETTING_&_RUN> menu
window, then select <2/2/A5 EXECUTE> and press the [ENTER] key. Block
conversion now starts.
7 Quit the command and save the data.
When block conversion is complete, press the [ESC] key to quit the current
command, then select <2/2/B5 RENAME & EXIT> and press the [ENTER]
key. Follow the message displayed on the screen to save the data.
Reference
When you want to save the data by overwriting the original data (when not necessary to
keep the original data), select <2/2/B0 SAVE & EXIT> and press the [ENTER] key.
n
Note
When block conversion is executed with the “BLOCK CONVERSION COND.” parameter
set to “1: CONV. WITH NOTE DATA”, the original block repeat data remains as “Note”
data.
Blk Repeat Info. screen after block conversion
27606-C0-00
No.
1
2
3
4
5
X
0.00
30.00
0.00
30.00
Y
0.00
0.00
50.00
50.00
Block Comment
BLOCK_1
BLOCK_2
BLOCK_3
BLOCK_4
Skip?
Exec
Exec
Exec
Exec
R
0.00
0.00
180.00
180.00
OBJ : Blk Repeat Info.PCB :
No.
1
2
3
4
5
X
0.00
30.00
0.00
30.00
Y
0.00
0.00
50.00
50.00
Block Comment
BLOCK_1
BLOCK_2
BLOCK_3
BLOCK_4
Skip?
Exec
Note
Note
Note
R
0.00
0.00
180.00
180.00
OBJ : Blk Repeat Info.PCB :
Before block conversion
Block repeat data remains as “Note” data.
After block conversion
6
-12
EPD8013110
Operation
Chapter 6
6
Using various functions
2.2.2 Reconverting to the block repeat data
When editing or correcting one-block PCB data which was converted from
block repeat data, it will prove convenient to use the original block repeat
data. This section explains how to reconvert such data into the original
block repeat data. This data reconversion is possible only when the block
conversion was executed under “1: CONV. WITH NOTE DATA”.
1 Select <2/2/A1 OBJECT SELECTION> and press the [EN-
TER] key.
The OBJECT SELECTION menu box then appears.
2 Execute the PCB SELECTION command and select the PCB
name.
When a list of the registered PCB names appears, select the PCB to
execute reconversion, then select “QUIT” and press the [ENTER] key.
3 Select <2/2/A4 CONDITION SETTING> and press the
[ENTER] key.
The DATA GENERATOR CONDITION menu box then appears.
4 Select “BLOCK CONVERSION CONDITION” to set the
conditions.
When the submenu box appears, line up the cursor with “3: CONV. BACK
TO BLOCK” and press the [ENTER] key.
BLOCK CONVERSION CONDITION menu box
27607-C0-00
0: NO
1: CONV. WITH NOTE DATA
2: CONV. WITHOUT NOTE DATA
3: CONV. BACK TO BLOCK
BLOCK CONVERSION CONDITION
Move the cursor to this item
and press the [ENTER] key.
5 Set the “FEEDER SET CONDITION” parameter.
Set this parameter to “NO” when performing only the block reconversion.
Refer to “9.2 Setting optimization conditions” in Chapter 5 for more
details.
6 Execute the reconversion.
Press the [ESC] key to return to the <2/2/A/SETTING_&_RUN> menu
window, then select <2/2/A5 EXECUTE> and press the [ENTER] key. The
reconversion now starts.
6
-13
EPD8013110
Operation
Chapter 6
6
Using various functions
Reconversion into the block repeat data
27608-C0-00
No.
1
2
3
4
5
X
0.00
30.00
0.00
30.00
Y
0.00
0.00
50.00
50.00
Block Comment
BLOCK_1
BLOCK_2
BLOCK_3
BLOCK_4
Skip?
Exec
Exec
Exec
Exec
R
0.00
0.00
180.00
180.00
OBJ : Blk Repeat Info.PCB :
No.
1
2
3
4
5
X
0.00
30.00
0.00
30.00
Y
0.00
0.00
50.00
50.00
Block Comment
BLOCK_1
BLOCK_2
BLOCK_3
BLOCK_4
Skip?
Exec
Note
Note
Note
R
0.00
0.00
180.00
180.00
OBJ : Blk Repeat Info.PCB :
Before block conversion
Block repeat data remains as “Note” data.
After block conversion
7 Quit the command and save the data.
When the reconversion is complete, press the [ESC] key to quit the current
command, then select <2/2/B0 SAVE & EXIT> and press the [ENTER] key.
Reference
If you want to save the reconverted data with a name different from the block-converted
data (in other words, if you want to keep the block-converted data), use the <2/2/B5
RENAME & EXIT> command.
c
CAUTION
• The data once converted into single PCB data under “2: CONV. WITHOUT NOTE
DATA” cannot be reconverted back into the original data.
• Changes or corrections you have made to the single PCB data which was converted
from block repeat data will not be reflected in the reconverted data.
• If you delete or copy the “Note” data, it cannot be reconverted back into the original
block repeat data.
