5 -3 EPD8013110 Operation Chapter 5 5 Creating the PCB data 1. Over view The PCB data is indexed b y means of each individual PCB name. Each PCB type consists of various information as sho wn below . Data management for …

100%1 / 307
6. Creating the PCB information ............................................ 5-89
6.1 Creating procedure................................................................. 5-91
6.2 PCB origin .............................................................................. 5-96
6.2.1 Normal PCB origin position setting 5-97
6.2.2 Setting the PCB origin at a position other than the locate pin 5-98
6.2.3 Setting the PCB origin for multi-block PCB 5-99
7. Creating the mount information....................................... 5-100
8. Checking the data ............................................................ 5-106
8.1 Checking the component information .................................. 5-106
8.2 Checking the mount information .......................................... 5-107
9. Data optimization ............................................................ 5-111
9.1 Selecting the data ................................................................. 5-112
9.2 Setting optimization conditions ............................................ 5-113
9.3 Optimizing the data ............................................................. 5-116
10. Mounting test and data correction ................................... 5-117
10.1 Making setups for mounting test ........................................... 5-118
10.2 Starting the test mount .......................................................... 5-121
10.3 Error countermeasures during mounting test ......................... 5-124
10.3.1 PCB data error 5-125
10.3.2 Fiducial mark recognition error 5-126
10.3.3 Component pickup error 5-128
10.3.4 Component recognition error 5-130
10.3.5 Component mount error 5-131
10.4 Correcting the data after mounting test ................................. 5-133
11. Data backup ..................................................................... 5-136
11.1 Creating a PCB data disk ...................................................... 5-137
11.2 Data backup......................................................................... 5-139
12. Teaching and trace ........................................................... 5-140
12.1 Trace .................................................................................... 5-140
12.2 Teaching ............................................................................... 5-142
12.2.1 Point teaching 5-142
12.2.2 Vision cursor teaching 5-143
12.3 Automatic trace .................................................................... 5-147
13. Data editing for production PCB ...................................... 5-148
13.1 Data editing ......................................................................... 5-148
13.1.1 Copying the specified range 5-148
13.1.2 Deleting the specified range 5-150
13.1.3 Inserting one line 5-151
13.1.4 Deleting one line 5-152
13.2 Data replace ......................................................................... 5-153
13.2.1 Data replace in mount information 5-153
13.2.2 Data replace in component information 5-156
13.3 Data sort .............................................................................. 5-159
5
-3
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
1. Overview
The PCB data is indexed by means of each individual PCB name. Each
PCB type consists of various information as shown below.
Data management for each PCB
23501-C0-00
PCB NAME MAIN WINDOW SUB WINDOW
PCB1
PCB2
PCB3
PCB Info.
Mount Info.
Component Info.
Mark Info.
Block Repeat Info.
Local Fidu. Info.
Local BadMrk Info.
1. BASIC INFO.
2. OPTION INFO.
3. PICK & MOUNT INFO.
4. DUMP INFO.
5. VISION INFO.
6. SHAPE INFO.
Mark Type Info.
Mark size Info.
Vision Info.
n
NOTE
This section describes basic methods for creating PCB data so that you will understand
what data is needed for what item. After you have obtained a complete understanding of
these methods, begin actual work according to the desired method.
5
-4
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
The flow chart below shows the basic procedure for creating new PCB
production data.
Flow chart for creating new PCB production data
23502-C0-00
Create Component Info.
Create PCB Info.
Create Mount Info.
Register and select
PCB names
Create database
Create Mark Info.
Create
Block Repeat Info.
Clamp PCB on conveyor
Create
Local Fidu. Info.
Create
Local Bad Mrk Info.
Check mounting position
and correct data
Data optimization
To PCB production
Test mount components
and correct the data
Make data backup
Chapter 6
☞
2
☞
3
☞
For fiducial mark
For badmark
4
☞
Chapter 6
☞
5
☞
6
☞
Chapter 6
☞
7
☞
Chapter 6
☞
Chapter 6
☞
8
☞
9
☞
10
☞
11
☞
Chapter 4
☞
Perform the shaded
items as needed.
