5
-12
EPD8008100
Operation
Chapter 5
5
Creating the PCB data
3.1 Creating procedure
When you have registered or selected the PCB name, create PCB data with
the following procedure.
1 Open the Component Info. screen.
Select “Component Info.” from the edit item menu box which appears
after registering or selecting a PCB name. If an edit screen is open, press
the [F3] key (or select <2/1/A1 MAIN WINDOW>) to display the edit item
menu box and select “Component Info.” .
Component Info. screen
27506-C0-00
<<<APPLICATION>>>
<<MODE>> 1/EDIT_DATA
PCB :
2/DATA/M
OBJ :Component Info.
COMMENTNo.
1
2
3
COMPONENT NAME
:
:
:
Main window
Sub-window
n
NOTE
Enter the component name and comment in the main window and various parameter
values in the sub-window. Parameter items in the sub-window appear when you press the
[ENTER] key after entering the component name. The sub-window consists of several
groups of information which are switched with the [F4] key. Press the [TAB] key to switch
between the main and sub windows.
2 Enter the component name and press the [ENTER] key.
Enter the name printed on the tape reel or on the component itself in the
COMPONENT NAME column on the main window within 20 alphanu-
meric characters. A space cannot be included in the name.
3 Enter a comment and press the [ENTER] key.
Type any desired comment in the COMMENT column as necessary. You
can omit entering comments here.
4 Copy sample data from the database.
1. Press the [ESC] key to display the <A/DISPLAY> menu window and
select the <A3 VIEW DATABASE NO.> command.
VIEW DATABASE NO. command
27507-C0-00
<<<APPLICATION>>>
<<MODE>>
<COMMAND_LIST>
2/DATA/M
1/EDIT_DATA
A/DISPLAY
A3 VIEW DATABASE NO.
5
-13
EPD8008100
Operation
Chapter 5
5
Creating the PCB data
2. A list of data registered in the database appears, so select the data of
the same component or the most similar component in shape and press
the [ENTER] key to make a copy.
The selected database No. is enteered in the DataBase Number column
in the BASIC INFO. sub-window. At the same time, various parameters
of the selected component are copied. Press any key to return to the
previous screen.
Database No. selection screen
27508-C0-00
1
2
3
4
<<<APPLICATION>>>
<<MODE>> 1/EDIT_DATA
<COMMAND_LIST>
A/DISPLAY
A3
2/DATA/M
503
500
501
502
503
R1005
R1608
R2125
R3216
Database No. :
Database No.
Component name
Selected database No. is
copied here automatically.
Reference
You can copy the database information without using the <2/1/A3 VIEW DATABASE
NO.> command as follows:
1. Press the [TAB] key to move the cursor to the Database No. column in the BASIC
INFO. sub-window.
2. Enter the database number you want to copy from.
3. Press the [F7] key to run the SET FROM DATABASE command, and the information
onthe specified database number is then copied.
Database No. in BASIC INFO. sub-window
27509-C0-00
1.BASIC INFO.
Database No. : 502
Enter the database No.
to be copied and press
the [F7] key.
Reference
If data is registered in the database with numbers 1001 to 1600, you can redisplay all
these pieces of data from 1001 in alphabetical order by placing the cursor on the <A3
VIEW DATABASE NO.> command and pressing the [SHIFT] + [ENTER] keys.
For details on the database, refer to “3. Creating the user database” in Chapter 6.
5
-14
EPD8008100
Operation
Chapter 5
5
Creating the PCB data
5 Set necessary parameters in the sub-windows.
Press the [TAB] key to move the cursor into the sub-window and set other
parameters as necessary. For more details, refer to the next sections “3.2”
to “3.7” in this chapter. (To switch the sub-windows, press the [F4] key.)
Reference
When using stick feeders, refer to “3.8 Setting the stick feeder component data” in this
chapter.
6 Run the Adjust Assistant.
Press the [F6] key or run the <2/1B1 ADJUST ASSISTANT> command to
enter the Adjust Assistant mode.
The commands in the Adjust Assistant mode are used to check or optimize
the data copied or registered. (Refer to “3.7 Adjust Assistant commands” in
this chapter for more details.)
7 Save the PCB data.
Exit the Adjust Assistant mode, then press the [ESC] key twice, select <2/1/
D8 SAVE PCB DATA> and press the [ENTER] key.
8 Repeat the above steps for other components.
Use the same procedure from Step 2 to register all components to be
mounted on the PCB.
