6
-48
EPD8013110
Operation
Chapter 6
6
Using various functions
6
1 Register the PCB data for self production.
In order to utilize self production control you must create a combination
of PCB data (hereafter called “SELF_PROD_EXAMPLE”) which is made up
of two or more units of PCB data (for example “PCB1” and “PCB2”) which
are to be successively supplied on the conveyor.
1. Use the <2/1/D2 CREATE PCB> command to register the PCB name
“SELF_PROD_EXAMPLE” for self production.
2. After registering the PCB name, press the [F2] key to select it
(“SELF_PROD_EXAMPLE”) for data creation.
Reference
If the “PCB1” or “PCB2” data is already registered, it will prove helpful to copy either
one with the <2/1/D4 COPY PCB DATA> command and then rename it to
“SELF_PROD_EXAMPLE”.
2 Create the mark information.
Open the Mark Info. screen and register the self production marks, just as
when registering normal fiducial marks. However, set the Mark Type
parameter to “Fid for Bad” and the Bad Mark Rev. parameter to “Reverse”.
Mark information settings for self production
27630-C0-00
Fid for Bad
Reverse
0
PCB:SELF_PROD_EXAMPLE
Mark Type Info.
Edit Term
Mark Type
Bad Mark Rev
DataBase Number
OBJ : Mark Info.
MARK NAME
Mark_1
Mark_2
No.
1
2
3
4
COMMENT
For PCB1
For PCB2
:
:
:
:
V
<<<APPLICATION>>> 2/DATA/M
<<MODE>> 1/EDIT_DATA
Data for PCB1
Data for PCB2
3 Create the component information
Open the Component Info. screen and register the data on all components
to be used for “PCB1” and “PCB2”. To create the component data, refer to
“3. Creating the component information” in Chapter 5.
If the component data is already registered in the “PCB1” and “PCB2”,
copying each of the data and pasting it in the “SELF_PROD_EXAMPLE” is
recommended. (Refer to “13. Data editing for production PCB” in Chapter
5 to make a copy.)
c
CAUTION
The component numbers of the copy source and copy destination must be the same in
order to paste the copied data.
If the component number is duplicated in the copy destination, change the component
number of either of the PCB data, and then change the “Component” in the Mount
Info. to match this change.
6
-49
EPD8013110
Operation
Chapter 6
6
Using various functions
4 Create the PCB information.
Referring to “6. Creating the PCB information” in Chapter 5, enter the
necessary settings for the PCB information.
Set to “Use” for the “LocalBadmark” parameter displayed on the lower
right of the PCB Info. screen.
Local badmark information settings for self production
27631-C0-00
PCB :
LocalBadmark Use
OBJ : PCB Info.
<<<APPLICATION>>> 2/DATA/M
<<MODE>> 1/EDIT_DATA
Set to “Use”.
5 Create the block repeat information.
When you are using multi-block PCBs, set the block repeat information.
Refer to “2.1 Creating the block repeat data” in this chapter. Skip this step
when you are using single PCBs.
6 Create the local badmark information.
Open the “LocalBadmrk Info.” screen and create the local badmark data
for each of “PCB1” and “PCB2” as follows.
Mark : Enter the mark No. registered for self produc-
tion in the mark information.
XY : Enter the XY coordinates of the center of the
mark relative Sœ the PCB origin (or block
origin in the case of block repeat reference).
Badmark Comment : Enter a comment so that you can identify the
PCB data for which this badmark is used.
Skip : Set to “Exec” (initial setting).
Local badmark information settings for self production
27632-C0-00
<<<APPLICATION>>> 2/DATA/M
<<MODE>> 1/EDIT_DATA
OBJ : LocalBadMrkInfo.
No.
1
2
Mark
1
2
X
5.00
230.00
Y
5.00
5.00
Badmark Comment
For PCB 1
For PCB 2
Skip
Exec
Exec
PCB:SELF_PROD_EXAMPLE
Data for PCB1
Data for PCB2
6
-50
EPD8013110
Operation
Chapter 6
6
Using various functions
6
7 Create the mount information.
Open the Mount Info. screen of the “SELF_PROD_EXAMPLE” and register
all the mount data used for the “PCB1” and “PCB2”. Be sure to enter the
local badmark No. for the “PCB1” registered in Step 6, in the “BadMk”
column for the “PCB1”, and enter the local badmark No. for the “PCB2” in
the “BadMk” column for the “PCB2”. For more details, refer to “7.
Creating the mount information” in Chapter 5.
Mount information settings for self production
27633-C0-00
PCB :
SignOfLandPattern
R1005
R2125
BadMk
1
2
OBJ :Mount Info.
No.
1
2
<<<APPLICATION>>> 2/DATA/M
<<MODE>> 1/EDIT_DATA
Comp
10
12
X
30.00
20.50
Y
45.00
10.00
R
0.00
0.00
Head
1
2
FidMk
0
0
Skip?
Exec
Exec
LocalBadMrk Info. data
No. for PCB1
LocalBadMrk Info. data
No. for PCB2
Reference
If the “PCB1” and “PCB2” mount data are already registered, copy each of the mount
data and paste them into the “SELF_PROD_EXAMPLE”. In this case, be sure to confirm
that all mount data on the “PCB1” and “PCB2” is registered with reference to the PCB
origin at the same coordinates. If not, change each piece of the mount data so that all
mount data refers to the PCB origin at the same coordinates.
