5 -155 EPD8013110 Operation Chapter 5 5 Creating the PCB data Y : Specify the Y column setting in the mount information with the number keys. R : Specify the R column setting in the mount information with the number keys…

100%1 / 307
5
-154
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
Comp : Select the Comp column setting in the mount
information with the number keys.
X : Select the X column setting in the mount
information with the number keys.
Y : Select the Y column setting in the mount
information with the number keys.
R : Select the R column setting in the mount
information with the number keys.
Head : Select the Head column setting in the mount
information with the number keys.
Fid Mk : Select the FidMk column setting in the mount
information with the number keys.
Bad Mk : Select the BadMk column setting in the mount
information with the number keys.
Skip? : Select the Skip? column setting in the mount
information with the [INS], [DEL] or [Space]
key.
LandPattren : Select the SignOflandPattern column setting in
the mount information with the [INS], [DEL]
or [Space] key.
ALL : Specify “ALL” if you want to replace all the
data registered in the mount informa-
tion.
2. When all the necessary settings are complete, press the [ENTER] key to
advance to the next step.
4 Set “Select change item”.
Select the parameter item you want to change and specify the new setting
that supersedes the current setting.
Setting for “Select change item” (Mount Info.)
27573-C0-00
Select condition item
Comp
3
Select change item
Skip?
Skip
Use number keys, [INS] or
[DEL] key to make setting
Use arrow keys to
make selection
1. Use the up/down arrow keys to select the parameter (shown in red) you
want to change. Then, enter or select the new setting for the selected
parameter with the number keys, or [INS], [DEL] or [Space] key.
Comp : Specify the Comp column setting in the mount
information with the number keys.
X : Specify the X column setting in the mount
information with the number keys.
5
-155
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
Y : Specify the Y column setting in the mount
information with the number keys.
R : Specify the R column setting in the mount
information with the number keys.
Head : Specify the Head column setting in the mount
information with the number keys.
Fid Mk : Specify the FidMk column setting in the mount
information with the number keys.
Bad Mk : Specify the BadMk column setting in the
mount
information with the number keys.
Skip? : Specify the Skip? column setting in the mount
information with the [INS], [DEL] or [Space]
key, to determine whether to perform
component mount.
X offset / Y offset : Enter the desired offset to add to or subtract
from the current XY data in the mount
information. For
example, if you want to shift the mounting
position selected in Step 3 by - 1mm in the X
or Y direction, enter “-1.00” here with the
number keys.
R offset : Enter the desired offset to add to or subtract
from the current R data in the mount informa-
tion. For example, if you want to change
the angle selected in Step 3 by 90 degrees,
enter “90.00” here with the number keys.
X / Y Sign Reverse : If you want to reverse the plus / minus signs
for the current X data in the mount informa-
tion, select “Use” with the [INS], [DEL] or
[Space] key. If not, select “None”. For
example, when set to “Use”, a setting of
“14.00” and vice versa.
2. When all the necessary settings are complete, press the [ENTER] key to
perform replace.
5
-156
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
13.2.2 Data replace in component information
1 Open the Component Info, screen.
2 Select the REPLACE command in the <2/1/EDIT_DATA>
mode.
1. Press the [ESC] key , select <2/1/C1 EDITOR ASSISTANT> and press the
[ENTER] key.
The EDITOR ASSISTANT submenu box appears.
2. Select “REPLACE” and press the [ENTER] key.
A box for data replace appears.
REPLACE command
27574-C0-00
<COMMAND_LIST>
R1608
R2125
R3216
1
2
3
C/EDIT_TOOL
C1 EDITOR ASSISTANT
EDITOR ASSISTANT
REPLACE
501
Tape
8mmTape
3 Set “Select condition item”.
1. Use the up/down arrow keys to select the parameter item (shown in
red) and then the setting you want to replace in the blue column just
under the parameter item.
Setting for “Select condition item” (Component Info.)
27575-C0-00
Select condition item
Component name
R1005
Select change item
Retry Times
2
Use arrow keys to
make selection
Use alphanumeric keys, [INS] or
[DEL] key to make setting
Component name : Select the COMPONENT name in the
component
information with the [INS], [DEL] or [Space]
key.
Nozzle Type : Select the Required Nozzle setting in the
BASIC INFO. sub-window of the component
information.
Use the [INS], [DEL] or [Space] key to make
the
selection.
