5
-7
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
The following steps explain the procedure in “1. Registering a new PCB
name”. For other methods, refer to the separate manual “YVOS 2 ” avail-
able from YAMAHA.
1 Select <2/1/D2 CREATE PCB DATA> and press the [ENTER]
key.
The Create PCB box then appears on the screen.
2 Enter a PCB name.
Enter a PCB name within 20 alphanumeric characters and press the
[ENTER] key. The message “NOT EXIST” then appears on the right in the
box and the cursor moves to the “Select Execute” parameter. (Refer to the
Caution below.)
Create PCB box
27501-C0-00
Create PCB
Destination
Select Execute
[INS][DEL] to change.
[ESC] to abort, [Enter] to finish.
PCB Name
MCH Name
NOT EXIST
: PCB1
: Machine
: CANCEL
Enter the PCB name here.
n
NOTE
A space cannot be included in a PCB name. Use underbars instead.
Example: SAMPLE PCB DATA --> SAMPLE_PCB_DATA
c
CAUTION
When the message “EXIST” appears in Step 2, this means that a PCB with the same
name has already been registered, so register another PCB name.
3 Set the “Select Execute” parameter to “EXECUTE”.
Use the [INS] [DEL] or [Space] key to select “EXECUTE” and press the
[ENTER] key. The PCB name has now been registered and then the menu
box for selecting the edit item appears.
Selecting “EXECUTE” to register the new PCB name
27502-C0-00
Create PCB
Select Execute
: EXECUTE
Use [INS], [DEL] or [Space] key to set to "EXECUTE".
5
-8
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
2.2 Selecting the PCB name
To edit the PCB data you already registered, you must first select the PCB
name.
1 Run the <2/1/D1 SWITCH PCB DATA> command.
The “pcb name” selection box then appears showing a list of registered
PCB names.
When you are already in the EDIT_DATA mode, pressing the [F2] key
displays the “pcb name” selection box.
PCB name selection box
27503-C0-00
pcb name
CONVEYOR
ANC_TEST
CUK_100
PCB1
2 Select the PCB name.
There are the following two methods for selecting the PCB name.
1. Using the arrow keys (or PageUp/PageDown keys)
Using the up/down arrow keys (or PageUp/PageDown keys), move the
cursor to the PCB name for which you will edit data, and press the
[ENTER] key.
2. Typing the PCB name
On the screen showing the PCB name selection box, you can select the
PCB name by typing its first few letters from the keyboard, in the
Search PCB box which appears upon typing the first letter of the PCB
name. At the same time, the cursor in the PCB name selection box
moves to a PCB name that matches the letters you typed. (This method
will prove convenient when many PCB names are already registered.)
When the target PCB is selected, press the [ENTER] key. To change the
PCB name you have just typed, press the [Back Space] key to delete the
last letter one by one and retype the correct letters.
Search PCB box
27504-C0-00
pcb name
CUK_92001_1
TCO1M2
TCO1M1
TCO1M1_P
Search PCB : CUK
Type the PCB name here.
Cursor moves as you type the PCB name
in the Search PCB box.
5
-9
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
3 Select the item you want to edit or create.
After you have selected the PCB name, the edit menu appears, so select
the item you want to edit or create.
The selected information screen then appears. The PCB name is displayed
on the top of the screen (DATA [ ] column).
Selecting the edit item
27505-C0-00
pcb name
CONVEYOR
ANC_TEST
PALLET_88
PCB1
OBJECT
PCB Info.
Mount Info.
Component
Mark
Blk Repeat
Local Fidu.
LocalBadMrkI
Info.
Info.
Info.
Info.
Info.
n
NOTE
To switch the PCB data on the edit screen, press the [F2] key (or select <2/1/D1 SWITCH
PCB DATA>) . To switch the edit item, press the [F3] key (or select <2/1/A1 MAIN
WINDOW>).
