5
-74
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
4.1 Creating procedure
1 Open the Mark Info. screen.
Select “Mark Info.” from the edit item menu box which appears after
registering or selecting a PCB name. If an edit screen is open, press the
[F3] key (or select <2/1/A1 MAIN WINDOW>) to display the edit item
menu box.
Mark Info. screen
27530-C0-00
PCB :
No.
1
2
3
4
5
MARK NAME COMMENT
Mark Type Info.
Edit Term :
OBJ :Mark Info.
<<<APPLICATION>>>
<<MODE>>1/EDIT_DATA
2/DATA/M
Mark Type
Database Number
Main window Sub-window
n
NOTE
Enter the mark name and comment in the main window and various parameter values in
the sub-window. The sub-window consists of several groups of information which are
switched with the [F4] key. Press the [TAB] key to switch between the main and sub
windows.
2 Move the cursor to data registration No.
3 Enter a mark name
Enter a different name for each mark in the MARK NAME column.
4 Enter a comment.
Type any desired comment on the mark as necessary in the COMMENT
column.
5 Copy sample data from the database.
1. Press the [ESC] key, select <A3 VIEW DATABASE NO.> and press the
[ENTER] key.
A list of marks registered in the database appears.
VIEW DATABASE NO. command
27531-D8-00
<<<APPLICATION>>>
<<MODE>> 1/EDIT_DATA
<COMMAND_LIST>
A/DISPLAY
A3 VIEW DATABASE NO.
2/DATA/M
5
-75
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
2. Use the UP/DOWN arrow keys or [PageUp] or [PageDown] key to
select the database number of the same mark or the most similar
mark in shape and press the [ENTER] key to make a copy.
The selected database No. is copied into the DataBase Number
column in the Mark Type Info. sub-window as well as other parameters
on the selected mark.
Database number selection screen
27532-C0-00
1
2
3
<<<APPLICATION>>>
<<MODE>> 1/EDIT_DATA
<COMMAND_LIST>
A/DISPLAY
A3
2/DATA/M
1
2
150
151
1.6mm_CIRCLE
1.0mm_CIRCLE
DOUBLE_CIR_1.6Cu
CIRCLE_1.0_Cu
Edit Term
Mark Type
DataBase Number
:
:
:
Fiducial
151
Mark nameDatabase number
Database No. and
parameters are copied.
Reference
You can copy the database information without using the <2/1/A3 VIEW DATABASE
NO.> command, as follows:
Press the [TAB] key to move the cursor to the right-hand screen (sub-window), then
enter the desired database number in the Database Number column in the Mark Type
Info. sub-window. Press the [F7] key to run the SET FROM DATABASE command,
and the information on the selected database number is then copied.
6 Set other parameters in the sub-windows.
Referring to “4.2 Various parameter settings” in this chapter, set other
parameters as necessary.
7 Run the Adjust Assistant.
Refer to “4.3 Adjust Assistant” in this chapter for more details.
8 Save the settings.
Exit the Adjust Assistant mode, then press the [ESC] key twice, select
<2/1/D8 SAVE PCB DATA> and press the [ENTER] key.
5
-76
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
4.2 Various parameter settings
This section describes how to set basic parameters in the mark information
sub-windows. Parameter settings not explained here should be found by
evaluating recognition results obtained with the Adjust Assistant or refer-
ring to the help message displayed by pressing the [F1] key.
Parameters for fiducial mark setting
27533-D8-00
Mark Type Info.
Edit Term
Mark Type
DataBase Number
:
:
:
Fiducial
297
Mark size Info.
Edit Term
MarkOutSizeX
MarkOutSizeY
Area
Perimeter
:
:
:
:
:
1.50
1.50
1.77
4.71
Vision Info.
Edit Term
Shape Type
Surface Type
Algorithm Type
Mark Threshold
Tolerance
Search Area
Outer Light
Inner Light
Coaxial Light
IR Outer Light
IR Inner Light
Cut Inner Noise
Cut Outer Noise
Sequence
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Sp. Shape
Reflect
Normal
Standard + 1
Standard + 1
Standard + 1
OFF
Standard + 1
0
0
Normal
115
30
3.00
1
2
3
4
5
6
7
8
9
10
n
NOTE
When setting the parameters shown in the sub-windows above, use the number keys to set
the parameters aligned on the right, while using the [INS], [DEL] or [Space] key to set
the parameters aligned on the left. However, there are some parameters which should be
set or optimized with the Adjust Assistant commands described later in “3.7” in this
chapter.
The Area and Perimeter parameters in the Mark Size Info. sub-window are displayed only
when the Shape parameter in the Vision Info, sub-window is set to “Sp. Shape”.
