5
-72
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
4. Creating the mark information
This section describes how to create mark information for fiducial marks
used on a PCB. Mark information has various parameters for each of the
mark names registered. To set these parameters, copy sample data of a
mark with a similar shape from the database and edit only the different
parameters.
Flow chart for creating mark information
23528-C0-00
4.2
☞
4.3
☞
Open
Mark Information
Enter COMMENT
Enter MARK
NAME
Copy database
information
Set various
parameters
Execute Adjust
Assistant
Save data
Reference
To create mark information on badmarks, see “6. Using badmark functions” in Chapter 6.
5
-73
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
VIOS structure for “Mark Info.”
23529-C0-00
A/DISPLAY
B/UTILITY
C/EDIT_TOOL
D/FILE
PCB Info.
Mount Info.
Component Info.
Mark Info.
Blk Repeat Info.
Local Fidu.Info.
LocalBadMrkInfo.
Mark Type Info.
Mark Size Info.
Vision Info.
1/OPERATION/M 2/DATA/M 3/MAINTE/M 4/SHELL/M 0/EXIT
1/EDIT_DATA
2/DATA_
GENERATOR
3/DATABASE 4/MANUAL 0/EXIT
A1 MAIN WINDOW
A2 SUB WINDOW
A3 VIEW DATABASE NO.
A4
VISION ALIGNMENT DIC
.
A5
A6
A7 FIND NEXT
A8
A9
A0 RETURN TO EDIT
B1 ADJUST ASSISTANT
B2 DATABASE UTILITY
B3
B4
DRAW THE SHAPE(CMP)
B5
B6 SET PALLET
B7 CONVEYOR UNIT
B8
B9
B0
TEACH,TRACE CONDITION
5
-74
EPD8013110
Operation
Chapter 5
5
Creating the PCB data
4.1 Creating procedure
1 Open the Mark Info. screen.
Select “Mark Info.” from the edit item menu box which appears after
registering or selecting a PCB name. If an edit screen is open, press the
[F3] key (or select <2/1/A1 MAIN WINDOW>) to display the edit item
menu box.
Mark Info. screen
27530-C0-00
PCB :
No.
1
2
3
4
5
MARK NAME COMMENT
Mark Type Info.
Edit Term :
OBJ :Mark Info.
<<<APPLICATION>>>
<<MODE>>1/EDIT_DATA
2/DATA/M
Mark Type
Database Number
Main window Sub-window
n
NOTE
Enter the mark name and comment in the main window and various parameter values in
the sub-window. The sub-window consists of several groups of information which are
switched with the [F4] key. Press the [TAB] key to switch between the main and sub
windows.
2 Move the cursor to data registration No.
3 Enter a mark name
Enter a different name for each mark in the MARK NAME column.
4 Enter a comment.
Type any desired comment on the mark as necessary in the COMMENT
column.
5 Copy sample data from the database.
1. Press the [ESC] key, select <A3 VIEW DATABASE NO.> and press the
[ENTER] key.
A list of marks registered in the database appears.
VIEW DATABASE NO. command
27531-D8-00
<<<APPLICATION>>>
<<MODE>> 1/EDIT_DATA
<COMMAND_LIST>
A/DISPLAY
A3 VIEW DATABASE NO.
2/DATA/M
