RH5 5.36 Y Lo ck Cy linder Replacement and Adjustment SERVICE MANUAL 5.36−4 DA3SEC−83−9U0−A0 = MEMO =
5.36 Y Lock Cylinder Replacement and Adjustment
SERVICE MANUAL
RH5
5.36−3
DA3SEC−83−9U0−A0
=CHECK=
When the head or the anvil swivels in X
direction in cutting the air off, retry the
above procedure (from 9 to 16).
=CHECK=
Replacement of the Y lock cylinder is
hazardous. Before replacing it, make
sure the digital sequence timer is set to
100q.
RH5
5.36 Y Lock Cylinder Replacement and Adjustment
SERVICE MANUAL
5.36−4
DA3SEC−83−9U0−A0
= MEMO =
5.37 Using the Digital Sequence Timer
SERVICE MANUAL
RH5
5.37−1
DA3SEC−83−9V0−A0
5.37 Using the Digital Sequence Timer
DA3SEC−83−9V0−A0
Sentence No.
5.37.1 Preparation
1. Turn power ON. (The initial screen will appear.)
2. Press “REQ” − “F6” (MORE) − “F1” (INITIAL DATA SET) − “F2” (MACHINE DATA SET) − “F6”
(MORE) in the order presented.
3. Using the arrow keys, set the digital sequence timer to “EDIT” and press “ENTER”.
4. Press “ENTER” again to complete the setting.
5. Press “ESC” o“F6” (MORE) o “REQ” o “F6” (TIMER).
6. The digital sequence timer screen appear with the function keys “F1” through “F6” at the lower part of
the screen.
ANGLE
CHANNEL
MODE
359
01
OFF
F1
(CH)
F2
(SET)
F3
(ON)
F4
(OFF)
F5
(T)
F6
(CLR)
=REFERENCE=
Turning power OFF and ON automatically sets the digital sequence timer to “ PROHIBIT UPDATE
“.
