Floppy disk interface(FDC) WD37C65
The WD37C65 is an FDC with built−in VFO capable of supporting up to 4 floppy disk drives and a floppy
disk drive interface driver/receiver.
Software is P PD765A compatible.
Command
I/O port
address
R/W
Operation resistor (LDOR) 40 W
Control register (LDCR) 42 W
Main status register read 48 R
Data register read 4A R
Data register write 4A W
Switch read 4C R
Control register write 4C W
(1) Operation register
D7
D6 D5 D4 D3 D2 D1 D0
OR7 OR6 OR5 OR4 OR3 OR2 OR1 OR0
(MSEL) (X) MOEN2 MOEN1 DMAEN SRST (X) DSEL
(2) Control register
D7
D6 D5 D4 D3 D2 D1 D0
* * * * * * OR1 OR0
*: Any setting is OK
CR1
CR0 Drive Baud rate Content
0
0
0
0
1
1
1
0
0
1
1
0
0
1
x
x
0
1
x
x
x
500 K
250 K
250 K
300 K
250 K
125 K
125 K
MFM
FM
MFM
MFM
MFM, RST (Factory setting)
FM, RST (Factory setting)
FM
RH5
8.3 List of Jumper Switch Settings
SERVICE MANUAL
8.3−22
DA3SEC−85−540−B0
(3) Switch read
D7
D6 D5 D4 D3 D2 D1 D0
S3 S2 S1 RDY 1 1 1 1
RDY
RDY is used to check the FDD unit state by indicating external line (READY) state.
READY = “H” o RDY = “0”
READY = “L” o RDY = “1”
S1−S3
S1−S3 indicate the state at JP17 1 to 3.
JP17
S
1
OPEN
S1
1
1
SHORT
S1
0
2
OPEN
S2
1
2
SHORT
S2
0
3
OPEN
S2
1
3
SHORT
S2
0
(4) Control register
D7
D6 D5 D4 D3 D2 D1 D0
RST * * DMAE MON TMSK * TTRG
Signal Content
RST
(RESET)
Used to initialize the FDC by being changed into an input signal at the RST terminal
on the FDC (WD37C65). It can be used when the transmission is out of sequence.
This signal can be operated under POWER−ON− RESET (and SW) and also OR.
DMAE
(DMA ENABLE)
Enables the DACK signal sent from the DMA channel to transmit data. Turn ON only
when using the DMA and OFF when not.
MON
(MOTOR ON)
Controls the drive motor for the FDD unit. Operated MOTOR ON to use this signal.
MON = “0” o MOTOR ON “H”
MON = “1” o MOTOR ON “L”
TMSK
(TIMER
INTERRUPT
MASK)
This is an interrupt mask bit to mask the timer interruption of FDC (hung−up timer).
Setting this bit 0 will mask the timer interruption. Immediately after power ON, set it
to “0”. Then also set to “0” when not using the timer.
TTRG
(TIMER TRIGGER)
Triggers the hung−up timer (one−shot, triggered to approx. 100 msec).
It is used to trigger the timer for FDD motor ON/OFF controlling.
Setting both TMSK and TIRG to 0 bit will lead to the interruption approx. 100 sec
later. The timer can be re−triggered within 100 msec after the timer was triggered.
8.3 List of Jumper Switch Settings
SERVICE MANUAL
RH5
8.3−23
DA3SEC−85−540−B0
(5) Jumper setting
Input jumpers for WD37C65 mode setting are as follows:
Jumper
Signal
name
Content
1of
JP12
DR
V
SHORT 0 16 MHZ
JP12
DR
V
OPEN 1 9.6 MHz
2of
JP12
PCV
AL
SHORT 0 187 nsec
JP12
PCV
AL
OPEN 1 125 nsec
Serial interface MB89371
This board is equipped with four serial I/O interface channels. They are controlled by the two SDTRs
(Serial data transmitter receiver MB89371).
The four channels are TTY, HOST, SIO1 and SIO2. The relationship between each I/O port address and
register is given below.
Used
device
I/O
address
R/W Register
30 R Receive data buffer register
30 W Send data buffer register
TTY
32 R Status register
TTY
32 W Mode/command register
34 W Baud rate setting register
36 W Mode setting register
38 R Receive data buffer register
38 W Send data buffer register
HOST
3A R Status register
HOST
3A W Mode/command register
3C W Baud rate setting register
3E W Mode setting register
50 R Receive data buffer register
50 W Send data buffer register
SIO1
52 R Status register
SIO1
52 W Mode/command register
54 W Baud rate setting register
56 W Mode setting register
58 R Receive data buffer register
58 W Send data buffer register
SIO2
5A R Status register
SIO2
5A W Mode/command register
5C W Baud rate setting register
5E W Mode setting register
