RH5 6.1 Checking Maintenance Precision SERVICE MANUAL 6.1−5 DA3SEC−89−010−A0 No. Check item Description Illustration Criteria Measured value 20 Pickup test Selector rod clearance setting T o be measured at 210 Bolt Whe…
6.1 Checking Maintenance Precision
SERVICE MANUAL
RH5
6.1−4
DA3SEC−89−010−A0
No.
Check item
Description
Illustration
Criteria
Measured
value
15
Bolt
M5 x 3
M6 x 4
M8 x 4
16
17
18
19
0to0.04mm
mm
0to0.04mm
0.50.1 mm
mm
mm
mm
mm
0to0.02mm
0to0.02mm
Anvil swing
precision (insertion
in X direction)
To be measured at
210
Measure the swing precision
of the anvil by moving the
measuring side of the dust
cover by 50 mm in X
direction with respect to the
XY table.
Pickup test
Pickup test
*******
Pickup test
Pickup test
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
Bolt
M6 x 2
M8 x 3
Bolt
M6 x 2
Bolt
M6 x 1
Bolt
M6 x 1
Anvil swing
precision (insertion
in Y direction)
To be measured at
210
In X direction
Guide pin height
precision
To be measured at
205
Ensure that the edge of the
pin is 0.5 mm below the top
end of the flat surface when
the lead guide pin is at the
uppermost position.
(Visually check with a scope.)
in Y direction
Guide pin
0.5
1.0
Guide pin swing
precision
(insertion in X
direction)
To be measured at
210
Measure the swing precision
of the guide pin by moving it
2 mm below the top surface
of the cartridge from the XY
table in X direction.
Measure the swing precision
of the anvil by moving the
measuring side of the dust
cover by 50 mm in Y
direction with respect to the
XY table.
Guide pin swing
precision
(insertion in Y
direction)
To be measured at
210
Measure the swing precision
of the guide pin by moving it
2 mm below the top surface
of the cartridge from the XY
table in Y direction.
Measuring
point
Measuring
point
RH5
6.1 Checking Maintenance Precision
SERVICE MANUAL
6.1−5
DA3SEC−89−010−A0
No.
Check item
Description
Illustration
Criteria
Measured
value
20
Pickup test
Selector rod
clearance setting
To be measured at
210
Bolt
When the guide pin is at
the uppermost position,
move the guide pin upper
cylinder up/down until three
pins are parallel to one
another. Then, set the
clearance 0.3 mm higher
than this position.
M3 x 2
21
22
23
24
mm
0.25 to 0.35 mm
mm
0to0.02mm
mm
0.5to0.7mm
OK/NG
Visual check
OK/NG
Visual check
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
Bolt
M5 x 1
Bolt
M6 nut x 2
Bolt
M5 x 2
Guide pin upper
stopper setting
To be measured at
210
Measure the clearance
between the guide pin and
stopper when the guide pin
is at the uppermost
position.
Movable blade
stroke
Measure the clearance
between the center lead cut
blade and movable blade at
the maximum stroke
position.
Insertion chuck
closing precision
Ensure that the chuck
rubber is not mispositioned
when the insertion chuck is
closed.
Insertion
chuck/guide chuck
closing center
Check the closing center of
the insertion chuck and
guide chuck at the 230
position.
Uppermost
position
Ensure clearance
here.
Clearance: 0
Stopper
Uppermost
position
Maximum stroke
position
Stroke
Insertion chuck
rubber
Insertion chuck
claw
Guide chuck
Insertion chuck
claw
Thickness gauge
Pin gauge
6.1 Checking Maintenance Precision
SERVICE MANUAL
RH5
6.1−6
DA3SEC−89−010−A0
No.
Check item
Description
Illustration
Criteria
Measured
value
25
26
27
28
29
OK/NG
Visual check
0to0.05mm
*******
mm
0to0.03mm
mm
0to0.03mm
mm
0to0.15mm
mm
Insertion pusher
and insertion
chuck center
Ensure that the insertion
pusher is aligned with the
insertion chuck.
Insertion pusher
Insertion chuck
rubber
Transfer chuck
Transfer chuck and
insertion chuck
center
To be measured at
90
Bolt
M8 x 4
Check the center of the
transfer chuck and insertion
chuck at the 90 position with
the closing position of the
insertion chuck as the
reference.
(Measure with a 0.2
mm−thickness gauge.)
Pickup test
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
OK/NG
White marker
check
Pickup test
Pickup test
Pickup test
Bolt
M5 x 1
Bolt
M5 x 2
Bolt M5 x 4
Positioner
positioning
precision
Measure the positioning
precision by checking for
clearance between the
positioner shaft and
bearing.
Clearance
Clearance
Positioning pin
PCB transfer rail
Positioning lever
Positioning lever
height
Positioning lever
installation
precision
Measure the height of the
positioning lever with the
transfer surface of the PCB
transfer rail as the
reference.
Measure the installation
precision by checking for
clearance between the
positioning lever and collar
on the reference side.
